LIP-8012D & LIP-8024D User Guide
5
phone (shown). Up to 2(without LIP-8048DSS) or 4(with
LIP-8048DSS) consoles can be chain-link connected to
the phone.DSS Connection to IP Phone
1.5.4 Wall Mount
The LIP-8000 series phones can be wall mounted as
needed. The following instructions describe how to
perform a wall mount installation. For more information
on installing your LIP-8000 series phone, refer to the
iPECS Hardware Description and Installation
Manual.
 Mark and drill two (2) 7mm holes for plastic wall
anchors.
 Insert the two (2) anchors into the holes and insert and
tighten the each screw leaving about 2.5 mm (1/8-
inch) of the screw exposed.
 Slide the LIP-8000 phone over the screws and assure
the phone is secure.
 NOTE—It may be necessary to remove the phone and
tighten or loosen the screws for a secure mounting.
