LG 19LC2D Service Manual

Copyright © 2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
- 7 -
5. Component Video Input (Y, PB, PR)
No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed
1 720*480 15.73 59.94 SDTV, DVD 480I
2 720*480 15.75 60.00 SDTV, DVD 480I
3 720*480 31.47 59.94 SDTV 480P
4 720*480 31.50 60.00 SDTV 480P
5 1280*720 44.96 59.94 HDTV 720P
6 1280*720 45.00 60.00 HDTV 720P
7 1920*1080 33.72 59.94 HDTV 1080I
8 1920*1080 33.75 60.00 HDTV 1080I
9 1920*1080 27 24 HDTV 1080P
10 1920*1080 33.75 30 HDTV 1080P
11 1920*1080 67.43 59.94 HDTV 1080P
12 1920*1080 67.5 60 HDTV 1080P
6. RGB Input (PC)
No Resolution H-freq.(kHz) V-freq.(kHz) Pixel clock(MHz) Remark Proposed
PC DDC
1 640*350 31.469 70.08 25.17 DOS
2 720*400 31.469 70.08 28.32 DOS O
3 640*480 31.469 59.94 25.17 VESA(VGA) O
4 800*600 37.879 60.31 40.00 VESA(SVGA) O
5 1024*768 48.363 60.00 65.00 VESA(XGA) O
7 1280*768 47.776 59.87 79.50 VESA(WXGA) O
8 1360*768 47.712 60.01 85.50 VESA(WXGA) O
9 1366*768 60.023 60.00 80.00 20/23LS7D only VESA(WXGA) O
10 1440*900 55.5 59.90 88.750 19LS4D-UA only WXGA
11 1680*1050 62.290 59.954 146.25 22LS4D-UA only WSXGA
No Resolution H-freq.(kHz) V-freq.(kHz) Pixel clock(MHz) Remark Proposed
PC DDC
1. 640*480 31.469 59.94 25.17 VESA(VGA) O
2. 800*600 37.879 60.31 40.00 VESA(SVGA) O
3. 1024*768 48.363 60.00 65.00 VESA(XGA) O
4. 1280*768 47.776 59.87 79.50 CVT(WXGA) O
5. 1360*768 47.720 59.799 84.75 CVT(WXGA) O
6. 1366*768 47.13 59.65 72
7. 1440*900 55.5 59.90 88.750 19LS4D-UA only WXGA
8. 1680*1050 62.290 59.954 146.25 22LS4D-UA only WSXGA
DTV
9. 720*480 31.469 59.94 27.00 SDTV 480P
10. 720*480 31.500 60.00 27.03 SDTV 480P
11. 1280*720 44.96 59.94 74.17 HDTV 720P
12. 1280*720 45.00 60.00 74.25 HDTV 720P
13. 1920*1080 33.72 59.94 74.17 HDTV 1080I
14. 1920*1080 33.75 60.00 74.25 HDTV 1080I
15. 1920*1080 27 24.00 74.25 HDTV 1080P
16. 1920*1080 33.75 30.00 74.25 HDTV 1080P
17. 1920*1080 67.43 59.94 148.35 HDTV 1080P
18. 1920*1080 67.5 60.00 148.50
7. HDMI/DVI input (PC)
