LG 32LC2R Series User Manual

6
INTRODUCTION
CONNECTION OPTION
INTRODUCTION
AV IN 2
L/MONO
R
AUDIOAUDIO
VIDEOVIDEO
VIDEO
AUDIO
COMPONENTCOMPONENT IN
RS-232C IN
(CONTROL & SERVICE)
ANTENNA
IN
VARIABLE
AUDIO OUT
2
1
AV OUT
CONTROL IN
REMOTE
RGB IN
RGB
(PC/DTV)(PC/DTV)
AUDIO
(RGB/DVI)
VIDEO
S-VIDEO
MONO
( )
AUDIO
AV IN 1
AC IN
HDMI/DVI IN
This is the back panel of models
4422PPCC11RR
**
,
5500PPCC11RR
**
,
5500PPCC33RR
**
TVs.
Back Connection Panel
AUDIO Input
Connections are available for listening
stereo sound from an external device.
VIDEO Input
Connects the video signal from a video
device.
Remote Control Port
RGB/Audio Input
Connect the monitor output from a PC/DTV to
the appropriate input port.
AV OUT
Connect the second TV or monitor to the
AV OUT socket on the set.
Variable Audio Output
Connect an external amplifier or add a sub
woofer to your surround sound system.
Power Cord Socket
This the set operates on an AC power. The volt-
age is indicated on the Specifications page.
Never attempt to operate the set on DC power.
HDMI/DVI Input
Connect a HDMI signal to HDMI/DVI IN.
Connect DVI(VIDEO) signal to HDMI/DVI port
with DVI to HDMI cable.
RS-232C Input
(CONTROL&SERVICE)Port
Connect the serial port of the control devices
to the RS-232C jack.
S-Video Input
Connect S-Video out from an S-VIDEO device.
Audio/Video Input
Connect audio/video output from an external
device to these jacks.
Component Input
Connect a component video/audio device to
these jacks.
Antenna Input
1
2
3
4
5
6
7
8
9
10
11
21 4 53
7 8 9
10 11
6
