LG 32LC51 Service Manual

- 29 -
C529 0CK332CK56A C1608X7R1H332KT 3.3nF 10% 50V X7R -55TO+125C
C530 0CK332CK56A C1608X7R1H332KT 3.3nF 10% 50V X7R -55TO+125C
C531 0CK332CK56A C1608X7R1H332KT 3.3nF 10% 50V X7R -55TO+125C
C532 0CK332CK56A C1608X7R1H332KT 3.3nF 10% 50V X7R -55TO+125C
C533 0CE106WH6DC MVK5.0TP25VC10M 10uF 20% 25V 25MA -40TO+105C
C534 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C535 0CC560CK41A C1608C0G1H560JT 56pF 5% 50V C0G -55TO+125C 16
C536 0CC560CK41A C1608C0G1H560JT 56pF 5% 50V C0G -55TO+125C 16
C537 0CC220CK41A C1608C0G1H220JT 22pF 5% 50V C0G -55TO+125C 16
C538 0CC220CK41A C1608C0G1H220JT 22pF 5% 50V C0G -55TO+125C 16
C539 0CE226WF6DC MVK5.0TP16VC22M 22uF 20% 16V 30MA -40TO+105C
C540 0CE226WF6DC MVK5.0TP16VC22M 22uF 20% 16V 30MA -40TO+105C
C541 0CE226WF6DC MVK5.0TP16VC22M 22uF 20% 16V 30MA -40TO+105C
C542 0CE226WF6DC MVK5.0TP16VC22M 22uF 20% 16V 30MA -40TO+105C
C543 0CE226WF6DC MVK5.0TP16VC22M 22uF 20% 16V 30MA -40TO+105C
C544 0CE226WF6DC MVK5.0TP16VC22M 22uF 20% 16V 30MA -40TO+105C
C545 0CE226WF6DC MVK5.0TP16VC22M 22uF 20% 16V 30MA -40TO+105C
C546 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C547 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C548 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C549 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C550 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C551 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C552 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C553 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C554 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C555 0CK106EF56A C3216X7R1C106KT 10uF 10% 16V X7R -55TO+125C 3
C556 0CK106EF56A C3216X7R1C106KT 10uF 10% 16V X7R -55TO+125C 3
C557 0CK106EF56A C3216X7R1C106KT 10uF 10% 16V X7R -55TO+125C 3
C558 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C559 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C563 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C564 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C568 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C569 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C570 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C571 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C572 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C573 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C573 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C574 0CE475WJ6DC MVK4.0TP35VC4.7M 4.7uF 20% 35V 15MA -40TO+85C
C575 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C575 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C576 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C600 0CK682CK51A C1608Y5P1H682KT 6.8nF 10% 50V Y5P -30TO+85C 1
C601 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 16V 80MA -40TO+105
C602 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C603 0CK682CK51A C1608Y5P1H682KT 6.8nF 10% 50V Y5P -30TO+85C 1
C604 0CK475EF67A C3216X5R1C475MT 4.7uF 20% 16V X5R -55TO+85C 3
C605 0CK475EF67A C3216X5R1C475MT 4.7uF 20% 16V X5R -55TO+85C 3
C607 0CK475EF67A C3216X5R1C475MT 4.7uF 20% 16V X5R -55TO+85C 3
C608 0CK475EF67A C3216X5R1C475MT 4.7uF 20% 16V X5R -55TO+85C 3
C609 0CE226WF6DC MVK5.0TP16VC22M 22uF 20% 16V 30MA -40TO+105C
C610 0CE475WJ6DC MVK4.0TP35VC4.7M 4.7uF 20% 35V 15MA -40TO+85C
C611 0CE475WJ6DC MVK4.0TP35VC4.7M 4.7uF 20% 35V 15MA -40TO+85C
C612 0CC471CK41A C1608C0G1H471JT 470pF 5% 50V C0G -55TO+125C 1
C613 0CC471CK41A C1608C0G1H471JT 470pF 5% 50V C0G -55TO+125C 1
C614 0CK475EF67A C3216X5R1C475MT 4.7uF 20% 16V X5R -55TO+85C 3
C615 0CK475EF67A C3216X5R1C475MT 4.7uF 20% 16V X5R -55TO+85C 3
C617 0CK475EF67A C3216X5R1C475MT 4.7uF 20% 16V X5R -55TO+85C 3
C618 0CK475EF67A C3216X5R1C475MT 4.7uF 20% 16V X5R -55TO+85C 3
C619 0CK102CK56A 0603B102K500CT 1nF 10% 50V X7R -55TO+125C 160
C620 0CK102CK56A 0603B102K500CT 1nF 10% 50V X7R -55TO+125C 160
C621 0CK682CK51A C1608Y5P1H682KT 6.8nF 10% 50V Y5P -30TO+85C 1
C622 0CK682CK51A C1608Y5P1H682KT 6.8nF 10% 50V Y5P -30TO+85C 1
C623 0CC270CK41A C1608C0G1H270JT 27pF 5% 50V C0G -55TO+125C 16
C624 0CK105DK94A 0805F105Z500CT 1uF -20TO+80% 50V Y5V -30TO+85
C625 0CK105DK94A 0805F105Z500CT 1uF -20TO+80% 50V Y5V -30TO+85
C626 0CK105DK94A 0805F105Z500CT 1uF -20TO+80% 50V Y5V -30TO+85
C627 0CK105DK94A 0805F105Z500CT 1uF -20TO+80% 50V Y5V -30TO+85
C628 0CE106WH6DC MVK5.0TP25VC10M 10uF 20% 25V 25MA -40TO+105C
C628 JCE8106J691 MVK5.0TP35VC10M 10uF 20% 35V 25MA -40TO+105C
C629 0CK105CF94A 0603F105Z160CT 1uF -20TO+80% 16V Y5V -30TO+85
C629 0CK105DK94A 0805F105Z500CT 1uF -20TO+80% 50V Y5V -30TO+85
C630 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C631 0CK105CF94A 0603F105Z160CT 1uF -20TO+80% 16V Y5V -30TO+85
C632 0CK224DK56A CS2012X7R224K500NR 220nF 10% 50V X7R -55TO+12
C633 0CK224DK56A CS2012X7R224K500NR 220nF 10% 50V X7R -55TO+12
C634 0CK224DK56A CS2012X7R224K500NR 220nF 10% 50V X7R -55TO+12
C635 0CK224DK56A CS2012X7R224K500NR 220nF 10% 50V X7R -55TO+12
C636 0CK105DK94A 0805F105Z500CT 1uF -20TO+80% 50V Y5V -30TO+85
C637 0CK105DK94A 0805F105Z500CT 1uF -20TO+80% 50V Y5V -30TO+85
C638 0CK105DK94A 0805F105Z500CT 1uF -20TO+80% 50V Y5V -30TO+85
C639 0CK105DK94A 0805F105Z500CT 1uF -20TO+80% 50V Y5V -30TO+85
C640 0CE477BJ618 ESM477M035T1G5H20G 470uF 20% 35V 610MA -55TO+
C641 0CE477BJ618 ESM477M035T1G5H20G 470uF 20% 35V 610MA -55TO+
C642 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C643 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C644 0CK105DK94A 0805F105Z500CT 1uF -20TO+80% 50V Y5V -30TO+85
C645 0CK105DK94A 0805F105Z500CT 1uF -20TO+80% 50V Y5V -30TO+85
C646 0CK474CH94A 0603F474Z250CT 470nF -20TO+80% 25V Y5V -30TO+
C647 0CE107WJ6DC MVK10TP35VC100M 100uF 20% 35V 310MA -40TO+85C
C648 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C649 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C650 0CK474CH94A 0603F474Z250CT 470nF -20TO+80% 25V Y5V -30TO+
C651 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C652 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C653 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C700 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C0G -55TO+125C 160
C701 0CE107WH6DC MVK8.0TP25VC100M 100uF 20% 25V 180MA -40TO+85
C702 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C703 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C704 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C708 0CE226SF6DC VMV226M016S0ANB010 22uF 20% 16V - -40TO+85C G
C709 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C710 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C711 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C712 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C713 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C714 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
LOC. NO. PART NO. DESCRIPTION / SPECIFICATION LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
www.freeservicemanuals.info
1/12/2013
Worldwide electronic heritage manuals

LG 32LC51 Specifications

General

Audio system	7w+7w
Number of speakers	2
I/O ports	PAL I/II, PAL/SECAM BG/DK/NTSC
Display diagonal	32 \
Display brightness	500 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Native aspect ratio	16:9
Contrast ratio (typical)	5000:1
SCART ports quantity	1
Product color	Black
Power consumption (standby)	1 W
Power consumption (typical)	150 W

Weight and Dimensions

Depth (with stand)	248.7 mm
Width (with stand)	806.8 mm
Height (with stand)	605.6 mm
Weight (with stand)	13100 g
Depth (without stand)	79 mm
Width (without stand)	806.5 mm
Height (without stand)	552.6 mm
Weight (without stand)	10700 g
