LG 32LC7R - Replacement Parts List - ICs, Resistors, Transistors; IC, Resistor, and Transistor Part Numbers

- 31 -
IC807 EAN32724702 STMAV340 4.0TO5.5V 5NSEC 5NSEC 0W TSSOP R/TP
IC809 0IPMG00049A AZ1117H-1.8TR/E1[H13A] 3.2TO10V 1.8V 0W SOT22
IC301 0TFTH80001A SSM6N15FU N-CHANNEL MOSFET 30V +-20V 100MA 0.
IC305 0TFTH80001A SSM6N15FU N-CHANNEL MOSFET 30V +-20V 100MA 0.
IC306 0TFTH80001A SSM6N15FU N-CHANNEL MOSFET 30V +-20V 100MA 0.
IC400 0TFTH80001A SSM6N15FU N-CHANNEL MOSFET 30V +-20V 100MA 0.
Q100 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q101 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q103 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q104 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q105 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q106 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q107 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q108 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q109 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q110 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q200 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q204 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q205 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q206 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q400 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q401 0TRIH80002A 2SA1530A-T112-1R PNP -6V -60V -50V -0.15A -0.
Q403 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q404 0TRIH80002A 2SA1530A-T112-1R PNP -6V -60V -50V -0.15A -0.
Q411 0TRIH80002A 2SA1530A-T112-1R PNP -6V -60V -50V -0.15A -0.
Q500 0TR102009AM KRA102S PNP -30V 0V -50V -0.1A -0.0000005A 50
Q501 0TRIH80002A 2SA1530A-T112-1R PNP -6V -60V -50V -0.15A -0.
Q502 0TRIH80002A 2SA1530A-T112-1R PNP -6V -60V -50V -0.15A -0.
Q503 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q504 0TRIH80002A 2SA1530A-T112-1R PNP -6V -60V -50V -0.15A -0.
Q600 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q601 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q602 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q603 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q700 EBK32753101 SI4925BDY P-CHANNEL MOSFET -30V +-20 -7.1A 0.
Q701 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q800 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q801 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q803 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
Q804 0TRIY80001A 2SC3052 NPN 6V 50V 50V 200MA 100NA 150TO800 1
L402 0RJ0000G676 MCR18EZHJ000_ 0OHM 5% 1/4W 3216 R/TP-T ROHM
L710 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/TP ROHM
R1 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/TP ROHM
R1 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/TP ROHM
R100 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/TP ROHM
R100 0RH0332D622 MCR10EZHJ330 33OHM 5% 1/8W 2012 R/TP ROHM
R100 0RJ0752D677 MCR03EZPJ750 75OHM 5% 1/10W 1608 R/TP ROHM
R101 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/TP ROHM
R101 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/TP ROHM
R101 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W 2012 R/TP ROHM
R101 0RH9101D622 MCR10EZHJ912 9.1KOHM 5% 1/8W 2012 R/TP ROHM
R101 0RJ9101D677 MCR03EZPJ912 9.1KOHM 5% 1/10W 1608 R/TP ROHM
R102 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W 2012 R/TP . ROHM
R102 0RH1101D622 MCR10EZHJ112 1.1KOHM 5% 1/8W 2012 R/TP ROHM
R102 0RH3301D622 MCR10EZHJ332 3.3KOHM 5% 1/8W 2012 R/TP ROHM
R102 0RH4700D622 MCR10EZHJ471 470OHM 5% 1/8W 2012 R/TP ROHM
R102 0RJ0752D677 MCR03EZPJ750 75OHM 5% 1/10W 1608 R/TP ROHM
R103 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/TP ROHM
R103 0RH1101D622 MCR10EZHJ112 1.1KOHM 5% 1/8W 2012 R/TP ROHM
R103 0RH2203D622 MCR10EZHJ224 220KOHM 5% 1/8W 2012 R/TP ROHM
R103 0RH3301D622 MCR10EZHJ332 3.3KOHM 5% 1/8W 2012 R/TP ROHM
R103 0RJ0752D677 MCR03EZPJ750 75OHM 5% 1/10W 1608 R/TP ROHM
R104 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/TP ROHM
R104 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W 2012 R/TP . ROHM
R104 0RH4700D622 MCR10EZHJ471 470OHM 5% 1/8W 2012 R/TP ROHM
R104 0RH9101D622 MCR10EZHJ912 9.1KOHM 5% 1/8W 2012 R/TP ROHM
R104 0RJ0752D677 MCR03EZPJ750 75OHM 5% 1/10W 1608 R/TP ROHM
R105 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/TP ROHM
R105 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/TP ROHM
R105 0RH2203D622 MCR10EZHJ224 220KOHM 5% 1/8W 2012 R/TP ROHM
R105 0RH9101D622 MCR10EZHJ912 9.1KOHM 5% 1/8W 2012 R/TP ROHM
R105 0RJ0752D677 MCR03EZPJ750 75OHM 5% 1/10W 1608 R/TP ROHM
R106 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/TP ROHM
R106 0RH0332D622 MCR10EZHJ330 33OHM 5% 1/8W 2012 R/TP ROHM
R106 0RH1101D622 MCR10EZHJ112 1.1KOHM 5% 1/8W 2012 R/TP ROHM
R106 0RH3301D622 MCR10EZHJ332 3.3KOHM 5% 1/8W 2012 R/TP ROHM
R106 0RJ3601D677 MCR03EZPJ362 3.6KOHM 5% 1/10W 1608 R/TP ROHM
R107 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W 2012 R/TP ROHM
R107 0RH1101D622 MCR10EZHJ112 1.1KOHM 5% 1/8W 2012 R/TP ROHM
R107 0RH3301D622 MCR10EZHJ332 3.3KOHM 5% 1/8W 2012 R/TP ROHM
R107 0RJ0752D677 MCR03EZPJ750 75OHM 5% 1/10W 1608 R/TP ROHM
R108 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/TP ROHM
R108 0RH0332D622 MCR10EZHJ330 33OHM 5% 1/8W 2012 R/TP ROHM
R108 0RH9101D622 MCR10EZHJ912 9.1KOHM 5% 1/8W 2012 R/TP ROHM
R108 0RJ2203D677 MCR03EZPJ224 220KOHM 5% 1/10W 1608 R/TP ROHM
R109 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W 2012 R/TP ROHM
R109 0RJ2203D677 MCR03EZPJ224 220KOHM 5% 1/10W 1608 R/TP ROHM
R110 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/TP ROHM
R110 0RJ2000D677 MCR03EZPJ201 200OHM 5% 1/10W 1608 R/TP ROHM
R111 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W 1608 R/TP ROHM
R112 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W 1608 R/TP ROHM
R114 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/TP ROHM
R115 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/TP ROHM
R116 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/TP ROHM
R117 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/TP ROHM
R119 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W 1608 R/TP ROHM
R120 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W 1608 R/TP ROHM
R121 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W 1608 R/TP ROHM
R122 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W 1608 R/TP ROHM
R132 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10W 1608 R/TP ROHM
R133 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10W 1608 R/TP ROHM
R140 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10W 1608 R/TP ROHM
R141 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10W 1608 R/TP ROHM
R153 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1608 R/TP ROHM
LOC. NO. PART NO. DESCRIPTION / SPECIFICATION LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
RESISTORs
TRANSISTORs & FETs
