BLOCK DIAGRAM
TX
IR & LED (P201)
IC603
HDMI (JK301)
HDMI_DATA
EEPROM
24C02
TMDS
Serial Flash (16MByte)
EEPROM
MAIN_SCL/SDA
IC301
IC602
HDMI_SCL/SDA
RGB_PC (JK102)
(SVC Only )
EEPROM
for HDCP (8K)
MAIN_SCL/SDA
SCL/SDA
MAIN SCLAER
Mi 8 LG7871
IC601
DSUB_SCL/SD A
COMPONENT
(JK100)
MNT_OUT
COMP_Y/Pb/Pr
COMPONENT_Y/Pb/Pr : 1/0.7Vpp
E-DIM
C
TXCE0±±
aria8-
(IC604)
COMPONENT_L/R : 500mVr ms
COMP_LIN/RIN
AV(JK101)
connect
TXCE2±± TXCE3±±
TXCLKE±±
TX E1±±
TXCO1±± TXCO3±± TXCO2±± TXCO0±±
TXCLKO±±
P202 P203 P204
AV_LIN/RIN : 500mVrms
R SPK OUT
AV_VIN : 1Vpp
PWM
AUDIO LOUT/ROUT : 500mVr ms
AV_VIN
AV_LIN/RIN
AUAMP_SCL/SDA
IC502
IC501
TV (RF)
L_SPK_OUT
__
NTP3100L
_ : m
TU_MAIN
L_CH
R_CH
IF
SIF
AUDIO_L/R OUT
AUDIO_OUT(JK103)
IIS_OUT
AMP
PANEL_STATUS
TUNER
TU401
VIF SAW Filter
SIF SAW Filter
RL_ON/I-DIMMING/DISP_EN
OPC_OUT
CONTROL (P200)
TUNER_SCL/SDA
AUDIO
(64K)
LIPS
orHD LVDS
