SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
4. Module specification(General)
1. Application range
This spec. sheet is applied to LCD TV used LP92A chassis.
2. Specification
Each part is tested as below without special appointment.
1) Temperature
: 25 ºC ± 5 ºC (77 ºF ± 9 ºF), CST : 40 ºC ± 5 ºC
2) Relative Humidity : 65 % ± 10 %
3) Power Voltage
: Standard input voltage(AC 100-240 V~ 50 / 60 Hz)
* Standard Voltage of each products is marked by models.
4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
5) The receiver must be operated for about 5 minutes prior to
the adjustment.
3. Test method
1) Performance: LGE TV test method followed
2) Demanded other specification
- Safety: CE, IEC specification
- EMC : CE, IEC
No. Item Specification Measurement Remark
1 Screen Size 80 cm(32 inch) wide Color Display Module Resolution : 1366*768
2 Aspect Ratio 16:9
3 LCD Module 80 cm(32 inch) TFT WXGA LCD
4 Operating Environment Temp. : 0 deg ~ 40 deg
Humidity : 0 % ~ 85 %
5 Storage Environment Temp. : -20 deg ~ 60 deg
Humidity : 0 % ~ 85 %
6 Input Voltage AC 100-240 V~ 50 / 60 Hz
7 Power Consumption ≤ 150 W
8 LCD Module 80 cm 760(H) x 450(V) x 48(D) Outline Dimension, Unit : mm
(32 inch) 510.75 x 170.25 x RGB Pixel Pitch, Unit : mm
12EEFL Backlight Assembly
Coating 3H
