LG 32LD340H Service Manual

LGE Internal Use OnlyCopyright LG Electronics. Inc. All right reserved.
Only for training and service purposes
- 10 -
8. HDMI input (PC/DTV)
No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock Proposed
PC DDC
1. 640*350 31.468 70.09 25.17 EGA X
2. 720*400 31.469 70.08 28.32 DOS O
3. 640*480 31.469 59.94 25.17 VESA(VGA) X
4. 800*600 37.879 60.31 40.00 VESA(SVGA) O
5. 1024*768 48.363 60.00 65.00 VESA(XGA) O
6. 1280*768 47.776 59.870 79.5 CVT(WXGA) O
7. 1360*768 47.712 60.015 85.50 VESA (WXGA) O
8. 1280*1024 63.981 60.020 108.00 VESA (SXGA) O
9. 1600*1200 75.000 60.000 162 VESA (UXGA) X
10. 1920*1080 67.500 60.000 148.50 HDTV 1080P O
DTV
1 720*480 31.50 60 27.027 SDTV 480P O
2 720*480 31.47 59.94 27.00 SDTV 480P O
3 1280*720 45.00 60.00 74.25 HDTV 720P O
4 1280*720 44.96 59.94 74.176 HDTV 720P O
5 1920*1080 33.75 60.00 74.25 HDTV 1080I O
6 1920*1080 33.72 59.94 74.176 HDTV 1080I O
7 1920*1080 67.500 60 148.50 HDTV 1080P O
8 1920*1080 67.432 59.939 148.352 HDTV 1080P O
9 1920*1080 27.000 24.000 74.25 HDTV 1080P O
10 1920*1080 26.97 23.976 74.176 HDTV 1080P O
11 1920*1080 33.75 30.000 74.25 HDTV 1080P O
12 1920*1080 33.71 29.97 74.176 HDTV 1080P O

LG 32LD340H Specifications

General

Equalizer	Yes
Audio system	Infinite Sound
RMS rated power	20 W
Built-in subwoofer	No
Number of speakers	2
Equalizer bands quantity	5
Comb filter	3D
Display diagonal	32 \
Display brightness	400 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Supported video modes	720p
Contrast ratio (dynamic)	60000:1
Screen format adjustments	16:9
Supported graphics resolutions	1366 x 768
Package depth	187.96 mm
Package width	982.98 mm
Package height	624.84 mm
Package weight	15560 g
Audio formats supported	MP3
Image formats supported	JPG
Video formats supported	MPEG2, MPEG4
Number of OSD languages	4
On Screen Display (OSD) languages	ENG, ESP, FRE, KOR
Backlight type	CCFL
Placement supported	Horizontal
Mean time between failures (MTBF)	60000 h
Certification	RoHS, CEC
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
HDMI version	1.3
RS-232 ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Panel mounting interface	200 x 100 mm
Remote control type	TLL-1100A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	150 W
Power consumption (standby)	1 W
Power consumption (typical)	80 W

Weight and Dimensions

Depth (with stand)	205.73 mm
Width (with stand)	805.18 mm
Height (with stand)	584.19 mm
Weight (with stand)	13060 g
Depth (without stand)	109.21 mm
Height (without stand)	528.31 mm
Weight (without stand)	11390 g
