LG 32LD340H Service Manual

LGE Internal Use OnlyCopyright LG Electronics. Inc. All right reserved.
Only for training and service purposes
1. Application range
This spec sheet is applied all of the 32”, 37”, 42” LCD TV with
LA06G/H chassis and 26” LCD TV with LA06H chassis.
2. Requirement for Test
Each part is tested as below without special appointment.
1) Temperature: 25 ºC ± 5 ºC
2) Relative Humidity: 65 ± 10 %
3) Power Voltage : Standard input voltage(100-240V~, 50/60Hz)
* Standard Voltage of each product is marked by models
4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
5) The receiver must be operated for about 5 minutes prior to
the adjustment.
3. Test method
1) Performance: LGE TV test method followed
2) Demanded other specification
- Safety : UL, CSA, IEC specification
- EMC: FCC, ICES, IEC specification
- 6 -
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement.
4. General Specification(TV)
No Item Specification Remark
1 Receivable System 1) ATSC / NTSC-M
2 Available Channel 1) VHF : 02 ~ 13
2) UHF : 14 ~ 69
3) DTV : 02 ~ 69
4) CATV : 01 ~ 135
5) CADTV : 01 ~ 135
3 Input Voltage 1) AC 100 ~ 120V 50/60Hz Mark : 110V, 60Hz
4 Market North America
5 Screen Size 32 / 37 / 42 inches
6 Aspect Ratio 16:9
7 Tuning System FS
8 LCD Module LC370WUE-SCA1 37LD340H-UA/37LD330H-UA
LC320WXE-SCA2 32LD340H-UA/37LD330H-UA
LC420WUE-SCA2 42LD340H-UA
9 Operating Environment Temp : 0 ~ 40 deg
Humidity : ~ 80 %
10 Storage Environment Temp : -20 ~ 60 deg
Humidity : -85 %

LG 32LD340H Specifications

General

Equalizer	Yes
Audio system	Infinite Sound
RMS rated power	20 W
Built-in subwoofer	No
Number of speakers	2
Equalizer bands quantity	5
Comb filter	3D
Display diagonal	32 \
Display brightness	400 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Supported video modes	720p
Contrast ratio (dynamic)	60000:1
Screen format adjustments	16:9
Supported graphics resolutions	1366 x 768
Package depth	187.96 mm
Package width	982.98 mm
Package height	624.84 mm
Package weight	15560 g
Audio formats supported	MP3
Image formats supported	JPG
Video formats supported	MPEG2, MPEG4
Number of OSD languages	4
On Screen Display (OSD) languages	ENG, ESP, FRE, KOR
Backlight type	CCFL
Placement supported	Horizontal
Mean time between failures (MTBF)	60000 h
Certification	RoHS, CEC
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
HDMI version	1.3
RS-232 ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Panel mounting interface	200 x 100 mm
Remote control type	TLL-1100A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	150 W
Power consumption (standby)	1 W
Power consumption (typical)	80 W

Weight and Dimensions

Depth (with stand)	205.73 mm
Width (with stand)	805.18 mm
Height (with stand)	584.19 mm
Weight (with stand)	13060 g
Depth (without stand)	109.21 mm
Height (without stand)	528.31 mm
Weight (without stand)	11390 g
