LG 32LD340H Service Manual

- 8 -
LGE Internal Use OnlyCopyright LG Electronics. Inc. All right reserved.
Only for training and service purposes
5.3. 32LD340H-UA/32LD330H-UA : LC320WXN-SCA2(LGD)
No. Item Min Typ Max Unit Remarks
1 White brightness 200 250 cd/m
2
EPA 4.0
2 Luminance uniformity 5point
3 Color coordinate RED X Typ. 0.636 Typ.
(Default) Y -0.03 0.335 +0.03
GREEN X 0.291
Y 0.603
BLUE X 0.146
Y 0.061
WHITE X 0.279
Y 0.292
4 Contrast ratio 900 1200 EPA 4.0, except RGB mode
10,000:1 50,000:1
6 Color Temperature Cool Typ. 0.269 Typ The W/B Tolerance is
-0.015 0.273 +0.015 ±0.015 for Adjustment
Medium Typ 0.285 Typ
-0.015 0.293 +0.015
Warm Typ 0.313 Typ
-0.015 0.329 +0.015
- EPA 4.0
Luminance : To qualify as ENERGY STAR under this specification, the peak luminance of the product in the ‘home” mode, or in the
default mode as shipped, shall not be less than 65% of the peak luminance of the “retail” mode, or the brightest selectable
preset mode, of the product.

LG 32LD340H Specifications

General

Equalizer	Yes
Audio system	Infinite Sound
RMS rated power	20 W
Built-in subwoofer	No
Number of speakers	2
Equalizer bands quantity	5
Comb filter	3D
Display diagonal	32 \
Display brightness	400 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Supported video modes	720p
Contrast ratio (dynamic)	60000:1
Screen format adjustments	16:9
Supported graphics resolutions	1366 x 768
Package depth	187.96 mm
Package width	982.98 mm
Package height	624.84 mm
Package weight	15560 g
Audio formats supported	MP3
Image formats supported	JPG
Video formats supported	MPEG2, MPEG4
Number of OSD languages	4
On Screen Display (OSD) languages	ENG, ESP, FRE, KOR
Backlight type	CCFL
Placement supported	Horizontal
Mean time between failures (MTBF)	60000 h
Certification	RoHS, CEC
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
HDMI version	1.3
RS-232 ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Panel mounting interface	200 x 100 mm
Remote control type	TLL-1100A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	150 W
Power consumption (standby)	1 W
Power consumption (typical)	80 W

Weight and Dimensions

Depth (with stand)	205.73 mm
Width (with stand)	805.18 mm
Height (with stand)	584.19 mm
Weight (with stand)	13060 g
Depth (without stand)	109.21 mm
Height (without stand)	528.31 mm
Weight (without stand)	11390 g
