LG 32LE2R Series User Manual

CONNECTIONS & SETUP
27
(R) AUDIO (L)
RGB-DTV OUTPUT
REMOTE
CONTROL IN
RS-232C INRS-232C IN
(CONTROL & SERSERVICE)
HDMI IN
AUDIO OUTUDIO OUT
VARIABLE
RGB INRGB IN
(PC/DTV)
AUDIO IN
(RGB)
RGB IN
(PC/DTV)
RS-232C IN
(CONTROL & SERVICE)
AUDIO OUT
VARIABLE
HDMI IN
DDiiggiittaall
SSeett--ttoopp BBooxx
1
2
When connecting with a D-sub 15 pin cable
Connect the RGB output of the digital set-top box to the
RRGGBB IINN ((PPCC//DDTTVV))
jack on the set.
Connect the audio outputs of the set-top box to the
AAUUDDIIOO IINN ((RRGGBB))
jack on the set.
Turn on the digital set-top box. (Refer to the owner’s
manual for the digital set-top box.)
1
2
3
Select RGB-DTV input source with using the
IINNPPUUTT
button on the remote control.
4
REMOTE
CONTROL IN
AUDIO IN
(RGB)
RGB INRGB IN
(PC/DTV)
RS-232C INRS-232C IN
(CONTR(CONTROLOL & SERSERVICE)VICE)
AUDIO OUTUDIO OUT
VARIABLE
HDMI IN
( )
AUDIO
VIDEO
S-VIDEO
AV IN 3
VIDEO
AUDIO
COMPONENT IN
HDMI-DVD OUTPUT
11
When connecting with a HDMI cable
Connect the HDMI output of the digital set-top box to the
HHDDMMII IINN
jack on the set.
Select HDMI input source with using the
IINNPPUUTT
button
on the remote control.
Turn on the digital set-top box. (Refer to the owner’s man-
ual for the digital set-top box.)
1
2
3
NOTE
!
GG
TV can receive the video and audio signal simultaneously with using a HDMI cable.
GG
If the digital set-top box supports Auto HDMI function, output resolution of the digital set-top box will be
automatically set to 1280x720p.
GG
If the digital set-top box does not support Auto HDMI, you need to set the output resolution appropri-
ately. To get the best picture quality, adjust the output resolution of the digital set-top box to
1280x720p.
DDiiggiittaall
SSeett--ttoopp BBooxx
