LG 32LE2R - Page 34

DATE: 2006. 10. 31.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R101 0RH9101D622 MCR10EZHJ912 9.1KOHM 5% 1/8W
R102 0RH3301D622 MCR10EZHJ332 3.3KOHM 5% 1/8W
R103 0RH1101D622 MCR10EZHJ112 1.1KOHM 5% 1/8W
R104 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R105 0RH9101D622 MCR10EZHJ912 9.1KOHM 5% 1/8W
R106 0RH3301D622 MCR10EZHJ332 3.3KOHM 5% 1/8W
R107 0RH1101D622 MCR10EZHJ112 1.1KOHM 5% 1/8W
R108 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
SW101 140-313B KPT-1115AM 1C1P 12VDC 0.05A
SW102 140-313B KPT-1115AM 1C1P 12VDC 0.05A
SW103 140-313B KPT-1115AM 1C1P 12VDC 0.05A
SW104 140-313B KPT-1115AM 1C1P 12VDC 0.05A
SW105 140-313B KPT-1115AM 1C1P 12VDC 0.05A
SW106 140-313B KPT-1115AM 1C1P 12VDC 0.05A
SW107 140-313B KPT-1115AM 1C1P 12VDC 0.05A
SW108 140-313B KPT-1115AM 1C1P 12VDC 0.05A
C300 0CH5101K416 C2012C0G1H101JT 100pF 5% 50V
C301 0CH5101K416 C2012C0G1H101JT 100pF 5% 50V
R300 0RH2203D622 MCR10EZHJ224 220KOHM 5% 1/8W
R301 0RH2203D622 MCR10EZHJ224 220KOHM 5% 1/8W
R302 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W 2
R303 0RH4700D622 MCR10EZHJ471 470OHM 5% 1/8W
R304 0RH4700D622 MCR10EZHJ471 470OHM 5% 1/8W
R305 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
C200 0CH5101K416 C2012C0G1H101JT 100pF 5% 50V
C201 0CH5330K416 C2012C0G1H330JT 33pF 5% 50V
C202 0CE4763F618 ESF476M016T1A5E05G 47uF 20%
C203 0CE4763F618 ESF476M016T1A5E05G 47uF 20%
D200 0DLAU0410AA SAW5670 ROUND 5mM AMBER/WHIT
IC201 6712000013A TSOP4438SO1 4.5TO5.5V 1.5MA
L200 0LC1032101A FI-C3216-103KJT 10UH 10% - 5
Q200 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50V
Q201 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50V
Q202 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50V
R200 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R201 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R202 0RH6800D622 MCR10EZHJ681 680OHM 5% 1/8W
R203 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R204 0RH6801D622 MCR10EZHJ682 6.8KOHM 5% 1/8W
R205 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R206 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R207 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R208 0RH3901D622 MCR10EZHJ392 3.9KOHM 5% 1/8W
- 34 -
SIDE A/V BOARD
PREAMP&LED BOARD
CONTROL BOARD
