19
(Except for LM577*, LM627*)
Wireless module (LGSBWAC92) Specifications
Wireless LAN (IEEE 802.11a/b/g/n/ac)
Frequency range Output Power (Max.)
2,400 to 2,483.5MHz 18dBm
5,150 to 5,725MHz 18dBm
5,725 to 5,850MHz 18dBm
Bluetooth
Frequency range Output power(Max.)
2,400 to 2,483.5MHz 8dBm
As band channels can vary per country, the user cannot change or adjust the operating frequency. This product is configured for the regional
frequency table.
For consideration of the user, this device should be installed and operated with a minimum distance of 20 cm (7.8 inches) between the device and
the body.
FCC ID: BEJLGSBWAC92
IC: 2703H-LGSBWAC92
Environment condition
Operating Temperature 0 °C to 40 °C (32 °F to 104 °F)
Operating Humidity Less than 80 %
Storage Temperature -20 °C to 60 °C (-4 °F to 140 °F)
Storage Humidity Less than 85 %
