EXPLODED VIEW PARTS LIST(37LC3R)
No.
PART NO.
DESCRIPTION
ACQ30233802 Cover Assembly, 37LC3R-ZH LP62A 37" 37LC3R-ZH cabinet assy(C/SKD)
6304FAU023A
LCD,Panel-TFT, T370XW01-V1 37INCH 1366X768 500CD COLOR 72% T370XW01-V1 500NITS 8MS 20LAMPS
ACQ30233902 Cover Assembly, 37LC3R-ZH LP61A 37" 37LC3R-ZH back cover assy(C/SKD)
ACQ30234002 Cover Assembly, 37LC3R-ZH LP61A 37" 37LC3R-ZH stand assy(C/SKD)
EBR32312801
PCB Assembly, SUB T.T LP62A 37LC3R-ZH_AUO_CKD_PREAMP_LED ASS`Y . H3-H LCD TV_IR
EBR30475201 PCB Assembly, SUB T.T LP62A 37LC2R-ZH ALL -SKD
EBR32312601
PCB Assembly, SUB T.T LP62A 37LC3R-ZH_AUO_CKD_CONTROL ASS`Y . H3-H LCD TV_CONTROL
EBR30695301 PCB Assembly, SUB S.T LP62A 37LC3R-ZH EKQH .-SKD
EAB30829201 Speaker,Woofer, g1560102 ND 15W 8OHM 82DB 100HZ 193 X 57 X 50 LUG
4950TKA361Z Plate, PRESS SBHG-A 1.6 METAL SBHG-A 37LC3R-ZH
49509K0341E Plate, PRESS EGI 1.6 SUPPORTER SPC AUO
49509K0340G Plate, PRESS EGI 1.6 SUPPORTER SPC 37LC2R(AUO) side frame (RIGHT, C/SKD)
EBR32312101
PCB Assembly, SUB T.T LP62A 37LC3R-ZH_AUO_CKD_SIDE AV . H3-H LCD TV_SIDE AV
68719ST984B PCB Assembly,Sub, SUB T.T LN61A 37LC3R-ZH ALEULFX SIDE A/V ASSY-SKD
6709900016D
SMPS,AC/DC, LGLP2637HEP 90.0VTO264.0V 215W 47TO63HZ UL/CSA/SEMKO YY / AT / HE
or 6709900016B Power Supply Assembly, FREE H3/E2 LCD MODEL LCD LG ELECTRONICS LB LC 37INCH
EBU32315901 Main Total Assembly, 37LC3R-ZH_AUO_CKD_MAIN BRAND LP62A
EBU32110601 Main Total Assembly, 37LC3R-ZH BRAND LP62A-SKD
4950TKA362Z Plate, PRESS SBHG1 0.8 SHIELD HGI 37LC3R-ZH
4810900107A Bracket, COVER 37LC3 LP62A ABS, HF-380 CALBLE MANAGEMANET
