EXPLODED VIEW PARTS LIST(42LC3R)
No.
PART NO.
DESCRIPTION
ACQ30234904 Cover Assembly, 42LC3R-ZH LP62A 42" 42LC3R-ZH cabinet assy(C/SKD)
6304FLP363A LCD,Panel-TFT, LC420W02-SLA1 42INCH 1365X768 500CD COLOR 72% -
ACQ30235303 Cover Assembly, 42LC3R-ZH LP61A 42" 42LC3R-ZH BACK COVER ASSY(C/SKD)
ACQ30235403 Cover Assembly, 42LC3R-ZH LP61A 42" 42LC3R-ZH STAND ASSY(C/SKD)
EAB30829201 Speaker,Woofer, g1560102 ND 15W 8OHM 82DB 100HZ 193 X 57 X 50 LUG
EBR32312801
PCB Assembly, SUB T.T LP62A 37LC3R-ZH_AUO_CKD_PREAMP_LED ASS`Y . H3-H LCD TV_IR
EBR30475201 PCB Assembly, SUB T.T LP62A 37LC2R-ZH ALL -SKD
EBR32355501
PCB Assembly, SUB T.T LP62A 42LC3R-ZH_CKD_CONTROL ASS`Y . H3-H LCD TV_CONTROL
EBR32231701 PCB Assembly, SUB T.T LP62A 42LC3R-ZH_SKD_CONTROL ASS`Y . H3-H LCD TV_CONTROL
AGU31055002 Plate Assembly, ASSY 42LC3R-ZH/MH(C/SKD) MAIN FRAME ASSY
6709900017C SMPS, YP4201-HDMI 90.0VTO264.0V 280W 47TO63HZ UL/CSA/TUV/SEMKO 42" LCD
or 6709900017B SMPS,AC/DC, YP4201 90.0VTO264.0V 280W 47TO63HZ UL/CSA/TUV/SEMKO 42" LCD
EBU32354901 Main Total Assembly, 42LC3R-ZH_CKD_MAIN ASS`Y BRAND LP62A
EBU32110701 Main Total Assembly, 42LC3R-ZH BRAND LP62A-SKD
EBR32355401
PCB Assembly, SUB T.T LP62A 42LC3R-ZH_CKD_SIDE AV ASS`Y . H3-H LCD TV_SIDE AV
EBR31784501 PCB Assembly, SUB T.T LP62C 42LC3R-ZH ALEULFX SIDE _AV ASSY-SKD
49509K0173Q Plate, PRESS EGI 0.8 SHIELD SBHG-A 42LC3R-ZH REAR SHIELD(C/SKD)
4810900108A Bracket, COVER 42LC3 LP62A ABS, HF-380 CABLE MANAGEMENT
