DATE: 2006. 07. 10.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R1895 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W-37LC3R
R1896 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W-42LC3R
R1897 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W-42LC3R
R856 0RJ1501D677 MCR03EZPJ152 1.5KOHM 5% 1/1-37LC3R
R856 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1-42LC3R
R858 0RJ1501D677 MCR03EZPJ152 1.5KOHM 5% 1/1-37LC3R
R858 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W-42LC3R
R1203 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W
R1214 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W
R1234 0RJ4702D677 MCR03EZPJ473 47KOHM 5% 1/10
R1235 0RJ4702D677 MCR03EZPJ473 47KOHM 5% 1/10
R1246 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10
R1247 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10
R1201 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10
R1207 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W
R1208 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W
R1209 0RJ2001D677 MCR03EZPJ202 2KOHM 5% 1/10W
R1223 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10
R1224 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10
R1226 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W
R1227 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W
R1228 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W
R1229 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W
R1230 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W
R1231 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W
R1232 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W
R1233 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W
R1248 0RJ1502D677 MCR03EZPJ153 15KOHM 5% 1/10
R1249 0RJ1502D677 MCR03EZPJ153 15KOHM 5% 1/10
X1200 6202TST001H SX-1 27MHZ 30PPM 27MHZ 30PP
X800 6212AB2015J HC-49SM 19.66080HZ 19.6608H
X400 156-A02M HC-49/U 18.432MHZ 30PPM 18.
D1003 0DL233309AC SAM2333 RED/Y-GREEN 2.7V 2.
D1103 0DL233309AC SAM2333 RED/Y-GREEN 2.7V 2.
X300 166-E02F CSBLA500KECZF09-B0 500KHZ 2
SW800 6600VR1004A SKHMPWE010 1C1P 12VDC 0.05A
SW900 6600VR1004A SKHMPWE010 1C1P 12VDC 0.05A
TU201 6700MF0017C TAFV-W303P PAL - - - 75OHM
C155 6102W5V016A AVRL161A1R1NT 10V 30% 1.1pF
C156 6102W5V016A AVRL161A1R1NT 10V 30% 1.1pF
C157 6102W5V016A AVRL161A1R1NT 10V 30% 1.1pF
C158 6102W5V016A AVRL161A1R1NT 10V 30% 1.1pF
C161 6102W5V016A AVRL161A1R1NT 10V 30% 1.1pF
C162 6102W5V016A AVRL161A1R1NT 10V 30% 1.1pF
C163 6102W5V016A AVRL161A1R1NT 10V 30% 1.1pF
C164 6102W5V016A AVRL161A1R1NT 10V 30% 1.1pF
SW101 140-313A THVV501BBC 1C1P 12VDC 0.05A
SW102 140-313A THVV501BBC 1C1P 12VDC 0.05A
SW103 140-313A THVV501BBC 1C1P 12VDC 0.05A
SW104 140-313A THVV501BBC 1C1P 12VDC 0.05A
SW105 140-313A THVV501BBC 1C1P 12VDC 0.05A
SW106 140-313A THVV501BBC 1C1P 12VDC 0.05A
SW107 140-313A THVV501BBC 1C1P 12VDC 0.05A
SW108 140-313A THVV501BBC 1C1P 12VDC 0.05A
R101 0RH1302D622 MCR10EZHJ133 13KOHM 5% 1/8W
R102 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8
DATE: 2006. 07. 10.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R103 0RH1501D622 MCR10EZHJ152 1.5KOHM 5% 1/8
R104 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
R105 0RH1302D622 MCR10EZHJ133 13KOHM 5% 1/8W
R106 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8
R107 0RH1501D622 MCR10EZHJ152 1.5KOHM 5% 1/8
R108 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
C101 0CH5101K416 C2012C0G1H101JT 100pF 5% 50
C102 0CH5101K416 C2012C0G1H101JT 100pF 5% 50
R102 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
R103 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
R104 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
R105 0RH4700D622 MCR10EZHJ471 470OHM 5% 1/8W
R106 0RH4700D622 MCR10EZHJ471 470OHM 5% 1/8W
D200 0DLAU0410AA SAW5670 ROUND 5mM AMBER/WHI
IC201 6712000013A TSOP4438SO1 4.5TO5.5V 1.5MA
C200 0CH5101K416 C2012C0G1H101JT 100pF 5% 50
C201 0CH5330K416 C2012C0G1H330JT 33pF 5% 50V
C202 0CE476VF6DC VGV476M016S0ANE010 47uF 20%
C203 0CE476VF6DC VGV476M016S0ANE010 47uF 20%
C204 0CE476VF6DC VGV476M016S0ANE010 47uF 20%
L200 0LC1032101A FI-C3216-103KJT 10UH 10% -
Q200 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50
Q201 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50
Q202 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50
R200 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
R201 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
R202 0RH4700D622 MCR10EZHJ471 470OHM 5% 1/8W
R203 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
R204 0RH4700D622 MCR10EZHJ471 470OHM 5% 1/8W
R205 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
R206 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2
R207 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W
R208 0RH4700D622 MCR10EZHJ471 470OHM 5% 1/8W
- 39 -
OTHERs
CONTROL BOARD
SIDE A/V BOARD
PREAMP&LED BOARD
