- 27 -
- Video Input level for S-Video/Component
500mV~1V700mV
800mV700mV
480i@60Hz,576i@50Hz
NTSC and PAL
ComponentS-Video
Input
IC spec
Measurement
waveform
Measurement
data
System
Input signal
* Measurement data for S-video/Component input amplitude at the point of
BCM3550 input pin
