EXPLODED VIEW PARTS LIST
No.
PART NO.
DESCRIPTION
120 EAB33775101 "Speaker,Full Range", EN1562C-6712 ND 10W 8OHM 82DB 100HZ 193.5 X 42 X 39.9 LUG KOREA TOPTONE
200 EAJ36548001 "LCD,Module-TFT", "LC370WX3-SLD1 WXGA 37INCH 1366X768 500CD COLOR 72% 16/9 900:1(DCR 5000:1) 6ms(GTG), Zero RT Pol. 10000K LG PHILIPS LCD"
300 ABJ32533605 Cabinet Assembly, "37LC7D-UB LA73E 37"" C/SKD NORTH AMERICA, PACIFIC2(BCM)"
310 ABA32533802 Bracket Assembly, "SPEAKER 37LC7 - GRILLE, LC7 FOR NORTH AMERICA"
400 ACQ32333510 Cover Assembly, "37LC7D-UB LA73E 37"" BACK, C/SKD NORTH AMERICA BCM"
500 EBR35527601 PCB Assembly, "SUB T.T LA63E 42LC2D-UA V668, BCM PRE AMP TOTAL ASSY"
510 EBR35527701 PCB Assembly, "SUB T.T LA73E 42LC7D-UB V668,BCM CONTROL TOTAL ASSY"
520 AGF33004001 Package Assembly, "SUB 42LC7D-UB V668,ACINLET,PACKING ASSY"
530 EBR35527001 PCB Assembly, "SUB T.T LA73E 42LC7D-UB V668, BCM SIDE A/V TOTAL ASSY"
600 EAY34796801
Power Supply Assembly, "LGIT_37inch FREE Torando 37inch LCD LGIT LCD Tornado 37inch (Power+Inverter) ¥Î«¸ PSU LG INNOTEK.,LTD."
610 EBT35606001 Chassis Assembly, MAIN LA74E 37LC7D-UA MAIN ASSY
800 MGJ32901202 Plate, PRESS EGI 1.2 FRAME SBHG-A 37LY3 METAL BAR TOP(C/SKD)
801 MGJ32901303
Plate, "PRESS EGI 1.6 FRAME SBHG-A 37LY3/37LC4 METAL BAR BOTTOM (NONE DVR),C/SKD"
802 MGJ32901403 Plate, PRESS EGI 1.2 FRAME SBHG-A 37LY3 METAL BAR RIGHT(C/SKD)
803 MGJ32901604 Plate, PRESS EGI 1.2 FRAME SBHG-A 37LC4 METAL BAR CENTER (V668)
804 MGJ34306202 Plate, "PRESS SBHG1-A 1.2 METAL SBHG-A 37"" V668 metal left,C/SKD"
805 MGJ32901709 Plate, "PRESS EGI 1.2 FRAME SBHG-A C/SKD 37LC4 METAL BAR SIDE TOP(D2A,BCM)"
806 MGJ32901809
Plate, "PRESS EGI 1.2 FRAME SBHG-A C/SKD 37LC4 METAL BAR SIDE BOTTOM (D2A,BCM)"
807 MGJ32901902 Plate, "PRESS EGI 1.2 FRAME SBHG-A 37LY3 METAL BAR SUPPORTER,C/SKD"
808 MGJ34304702
"Plate,Shield", "PRESS SBHG1-A 1.6 METAL EGI 37"" common Stand plate cover(for W/O stand),C/SKD"
810 MGJ32918108 "Plate,Shield", "PRESS SPTE 0.5 SHIELD SPTE 37"" upper for pacific2 chassis ""02"" C/SKD"
820 MAZ32930601 Bracket, MOLD ABS COVER 37LC4 LA71A ABS CABLE MANAGEMENT
830 EAM35501401
"Filter,AC Line", IF3-N06CEWL1 5.3mH 250VAC 6A 0.22uF 1000pF UL/CSA/VDE/K HOUSING/RING BK DONG IL TECHNOLOGY LTD.
840 MAZ34234901 Bracket, MOLD ABS STAND 37LC5 - ABS GUIDE
900 AAN33023904 Base Assembly, "STAND 37LB4DS-UA LD73A XG569,STAND ASSY(NO PRINT),(C/SKD)"
