EXTERNAL EQUIPMENT SETUP
EXTERNAL EQUIPMENT SETUP
Connecting a set-top box with a HDMI cable
Connect the HDMI output of the digital set-top box to the
HHDDMMII//DDVVII IINN 11,, HHDDMMII IINN 22
(Except 22LG3***) or
HHDDMMII IINN 33
(
Only 32/37/
42/47/52LG5
***
) jack on the TV.
Select
HHDDMMII11//DDVVII,, HHDDMMII22
(Except 22LG3***) or
HHDDMMII33
( Only 32/37/ 42/47/52LG5
***
) input source
using the
IINNPPUUTT
button on the remote control.
Turn on the digital set-top box.
(
Refer to the owner’s manual for the digital set-top box.
)
2
3
1
GG
TV can receive the video and audio signal simultaneously with using a HDMI cable.
GG
If the digital set-top box supports Auto HDMI function, the output resolution of the source device will be
automatically TV to 1280x720p.
GG
If the digital set-top box player does not support Auto HDMI, you need to TV the output resolution
appropriately. To get the best picture quality, adjust the output resolution of the source device to
1280x720p (42LG31F
**
,
32/ 37/42/47/52LG5
***
: 1920x1080i/1080p).
