- 8 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
6.2. PC mode
No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Remarks
1 640 x 350 @70Hz 31.468 70.09 EGA
2 720 x 400 @70Hz 31.469 70.08 DOS
3 640 x 480 @60Hz 31.469 59.94 VESA(VGA)
4 800 x 600 @60Hz 37.879 60.31 VESA(SVGA)
5 1024 x 768 @60Hz 48.363 60.00 VESA(XGA)
6 1152 x 864 @60Hz 54.348 60.053 VESA
7 1280 x 1024 @60Hz 63.981 60.020 VESA(SXGA) FHD only
8 1360 x 768 @60Hz 47.712 60.015 VESA(WXGA)
9 1920 x 1080 @60Hz 67.5 60.00 WUXGA(CEA 861D) FHD only
6. HDMI Input
6.1. DTV mode
No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Remarks
1. 640*480 31.469 59.94 SDTV 480P
2. 648*480 31.5 60.00 SDTV 480P
3. 720*480 15.73 59.97 SDTV, DVD 480I(525I)
Spec. out but display4. 720*480 15.75 60 SDTV, DVD 480I(525I)
5. 720*576 15.625 50 SDTV, DVD 576I(625I) 50Hz
6. 720*480 31.47 59.94 SDTV 480P
7. 720*480 31.5 60 SDTV 480P
8. 720*576 31.25 50 SDTV 576P
9. 1280*720 44.96 59.94 HDTV 720P
10. 1280*720 45 60 HDTV 720P
11. 1280*720 37.5 50 HDTV 720P
12. 1920*1080 28.125 50 HDTV 1080I
13. 1920*1080 33.72 59.94 HDTV 1080I
14. 1920*1080 33.75 60.00 HDTV 1080I
15. 1920*1080 26.97 23.976 HDTV 1080P
16. 1920*1080 27.00 24.000 HDTV 1080P
17. 1920*1080 33.71 29.97 HDTV 1080P
18. 1920*1080 33.75 30.00 HDTV 1080P
19. 1920*1080 56.25 50.00 HDTV 1080P
20. 1920*1080 67.432 59.94 HDTV 1080P
21. 1920*1080 67.5 60.00 HDTV 1080P
