- 9 -
6. Component Video Input(Y, PB
, PR)
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed
1. 720*480 15.73 59.94 13.500 SDTV, DVD 480I(525I)
2. 720*480 15.75 60.00 13.514 SDTV, DVD 480I(525I)
3. 720*576 15.625 50.00 13.500 SDTV, DVD 576I(625I)
4. 720*480 31.47 59.94 27.000 SDTV 480P
5. 720*480 31.50 60.00 27.027 SDTV 480P
6. 720*576 31.25 50.00 27.000 SDTV 576P
7. 1280*720 44.96 59.94 74.176 HDTV 720P
8. 1280*720 45.00 60.00 74.250 HDTV 720P
9. 1280*720 37.50 50.00 74.25 HDTV 720P 50Hz
10. 1920*1080 33.75 60.00 74.250 HDTV 1080I
11. 1920*1080 67.5 60.00 148.5 HDTV 1080P
12. 1920*1080 28.125 50 74.25 HDTV 1080I 50Hz
13. 1920*1080 56.25 50 148.5 HDTV 1080P 50Hz
8. RGB Input(DTV)
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed
1. 720*480 31.47 59.94 27.000 SDTV 480P
2. 720*480 31.50 60.00 27.027 SDTV 480P
3. 720*576 31.25 50.00 27.000 SDTV 576P
4. 1280*720 44.96 59.94 74.176 HDTV 720P
5. 1280*720 45.00 60.00 74.250 HDTV 720P
6. 1280*720 37.50 50.00 74.25 HDTV 720P 50Hz
7. 1920*1080 33.75 60.00 74.250 HDTV 1080I
8. 1920*1080 67.5 60.00 148.5 HDTV 1080P
9. 1920*1080 28.125 50 74.25 HDTV 1080I 50Hz
10. 1920*1080 56.25 50 148.5 HDTV 1080P 50Hz
7. RGB Input(PC)
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed
1 720*400 31.469 70.08 28.32 DOS
2. 640*480 31.469 59.94 25.17 VESA(VGA)
3 640*480 37.500 75.00 31.50 VESA(VGA)
4 800*600 37.879 60.31 40.00 VESA(SVGA)
5 800*600 46.875 75.00 49.50 VESA(SVGA)
6 832*624 49.725 74.55 57.28 Macintosh
7 1024*768 48.363 60.00 65.00 VESA(XGA)
8 1024*768 56.476 70.06 75.00 VESA(XGA)
9 1024*768 60.023 75.02 78.75 VESA(XGA)
10 1360*768 47.700 60.00 84.62 WXGA
11 1280*1024 63.668 59.895 109.00 SXGA
12 1400*1050 65.317 59.978 121.75 SXGA
13 1600*1200 74.537 59.978 121.75 UXGA
14 1920*1080 66.587 59.934 138.50 WUXGA(Reduced Blanking)
15 1920*1200 74.038 59.950 154.00 WUXGA(Reduced Blanking)
