Copyright © 2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
- 11 -
9. General specifications
9-1. 42" LCD Full HD(LC420WU2-SLB2)
No Item Specification Unit Remark
1 Active Screen Size 42.026 inches(1067.31mm) mm
2 Outline dimension 983.0(H)x576.0(V)x51.0(D) mm
3 Pixel Pitch 0.4845x0.4845 mm
4 Pixel Format 1920 horiz. By 1080 vert. RGB Stripe arrangement
5 Color Depth 8-bit / 16.7M Color
6 Luminance, White 550 cd/m2(Center 1point,Typ)
7 Power Consumption Total 167.3 Watt(Typ)
8 Weight 13.0Kg(Typ)
9 Display Operating Mode Transmissive Mode, Normally Black
10 Surface Treatment
Hard Coating (3H) Anti-glare treatment of the front polarizer
9-2. 47" LCD MODULE (LC470WU1-SLB2)
No Item Specification Unit Remark
1 Active Screen Size 46.96 inches(1192.87mm)
2 Outline dimension 1096.0(H)x640.0(V)x481(D) mm
3 Pixel Pitch 0.5415x0.5415x RGB mm
4 Pixel Format 1920 horiz by 1080 vert. RGB Stripe arrangement
5 Color Depth 8-bit / 16.7M Color
6 Luminance, White 550 cd/m2 kg
7 Power Consumption Total 230.56 Watt
8 Weight 20.0Kg
9 Display Operating Mode Transmissive Mode, Normally Black
10 Surface Treatment
Hard Coating (3H), Anti-glare treatment of the front polarizer
9-3. 52" LCD MODULE (LC520WU1-SLB1)
No Item Specification Unit Remark
1 Active Screen Size TBD
2 Outline dimension TBD mm
3 Pixel Pitch TBD mm
4 Pixel Format 1920 horiz by 1080 vert. RGB Stripe arrangement
5 Color Depth TBD
6 Luminance, White TBD kg
7 Power Consumption TBD
8 Weight TBD
9 Display Operating Mode Transmissive Mode, Normally Black
10 Surface Treatment
Hard Coating (3H), Anti-glare treatment of the front polarizer
