- 52 -
C712 0CK104CK56A "Capacitor,Ceramic,Chip" 0603B104K500CT 100nF 1
C713 0CK225DD66A "Capacitor,Ceramic,Chip" LMK212JB225MG-T 2.2uF
C714 0CK225DD66A "Capacitor,Ceramic,Chip" LMK212JB225MG-T 2.2uF
C715 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C716 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C717 0CK101BK4EA "Capacitor,Ceramic,Chip" C1005C0G1H101JT 100pF
C718 0CK101BK4EA "Capacitor,Ceramic,Chip" C1005C0G1H101JT 100pF
C722 0CK101BK4EA "Capacitor,Ceramic,Chip" C1005C0G1H101JT 100pF
C723 0CK101BK4EA "Capacitor,Ceramic,Chip" C1005C0G1H101JT 100pF
C728 0CK471BK56A "Capacitor,Ceramic,Chip" C1005X7R1H471KT 470pF
C729 0CK471BK56A "Capacitor,Ceramic,Chip" C1005X7R1H471KT 470pF
C733 0CK471BK56A "Capacitor,Ceramic,Chip" C1005X7R1H471KT 470pF
C735 0CK104CK56A "Capacitor,Ceramic,Chip" 0603B104K500CT 100nF 1
C742 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C743 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C744 0CC102CK41A "Capacitor,Ceramic,Chip" C1608C0G1H102JT 1nF 5%
C746 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C763 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C764 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C765 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C766 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C767 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C768 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C769 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C770 0CK104CK56A "Capacitor,Ceramic,Chip" 0603B104K500CT 100nF 1
C801 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C811 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C823 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C845 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C846 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C848 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C882 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C9000 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C9001 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C9002 0CC100BKF1A "Capacitor,Ceramic,Chip" 0402N100J500LT 10pF 5%
C9004 0CK102BK56A "Capacitor,Ceramic,Chip" 0402B102K500CT 1nF 10%
C9005 0CC100BKF1A "Capacitor,Ceramic,Chip" 0402N100J500LT 10pF 5%
C9008 0CK106EF56A "Capacitor,Ceramic,Chip" C3216X7R1C106KT 10uF 1
C9010 0CK103CK56A "Capacitor,Ceramic,Chip" 0603B103K500CT 10nF 10
C9012 0CK104CK56A "Capacitor,Ceramic,Chip" 0603B104K500CT 100nF 1
C9016 0CC102CK41A "Capacitor,Ceramic,Chip" C1608C0G1H102JT 1nF 5%
C9017 0CK106EF56A "Capacitor,Ceramic,Chip" C3216X7R1C106KT 10uF 1
C9018 0CK102BK56A "Capacitor,Ceramic,Chip" 0402B102K500CT 1nF 10%
C9019 0CK102BK56A "Capacitor,Ceramic,Chip" 0402B102K500CT 1nF 10%
C9020 0CK104CK56A "Capacitor,Ceramic,Chip" 0603B104K500CT 100nF 1
C9022 0CK103CK56A "Capacitor,Ceramic,Chip" 0603B103K500CT 10nF 10
C9024 0CK104CK56A "Capacitor,Ceramic,Chip" 0603B104K500CT 100nF 1
C9025 0CK103CK56A "Capacitor,Ceramic,Chip" 0603B103K500CT 10nF 10
C9027 0CK104CK56A "Capacitor,Ceramic,Chip" 0603B104K500CT 100nF 1
C9028 0CK102BK56A "Capacitor,Ceramic,Chip" 0402B102K500CT 1nF 10%
C9029 0CK106EF56A "Capacitor,Ceramic,Chip" C3216X7R1C106KT 10uF 1
C9031 0CK104CK56A "Capacitor,Ceramic,Chip" 0603B104K500CT 100nF 1
C9032 0CK104CK56A "Capacitor,Ceramic,Chip" 0603B104K500CT 100nF 1
C9034 0CK102BK56A "Capacitor,Ceramic,Chip" 0402B102K500CT 1nF 10%
C9036 0CK106EF56A "Capacitor,Ceramic,Chip" C3216X7R1C106KT 10uF 1
C9037 0CK102BK56A "Capacitor,Ceramic,Chip" 0402B102K500CT 1nF 10%
C9080 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C9083 0CK103BH56A "Capacitor,Ceramic,Chip" C1005X7R1E103KT- 10nF
C9083 0CK103CK56A "Capacitor,Ceramic,Chip" 0603B103K500CT 10nF 10
C9085 0CK106EF56A "Capacitor,Ceramic,Chip" C3216X7R1C106KT 10uF 1
D303 0DD184009AA Diode Assembly KDS184 KDS184 TP KEC -
D304 0DD184009AA Diode Assembly KDS184 KDS184 TP KEC -
D402 0DD184009AA Diode Assembly KDS184 KDS184 TP KEC -
D404 0DD184009AA Diode Assembly KDS184 KDS184 TP KEC -
D405 0DD184009AA Diode Assembly KDS184 KDS184 TP KEC -
D408 0DD184009AA Diode Assembly KDS184 KDS184 TP KEC -
D300 0DSGD00038A "Diode,Switching" 1N4148W 1.25V 100V 150
D9000 0DS226009AA "Diode,Switching" KDS226 1.2V 85V 300MA
D9001 0DS226009AA "Diode,Switching" KDS226 1.2V 85V 300MA
D301 0DRSE00038A "Diode,TVS" SDC15 1.3V 14.3VTO16.4
D302 0DRSE00038A "Diode,TVS" SDC15 1.3V 14.3VTO16.4
ZD300 0DZ330009GB "Diode,Zener" UDZS3.3B 3.3V 3.32TO3.
ZD405 0DZ360009EB "Diode,Zener" UDZS3.6B 3.6V 3.6TO3.8
ZD406 0DZ360009EB "Diode,Zener" UDZS3.6B 3.6V 3.6TO3.8
ZD407 0DZ560009DA "Diode,Zener" UDZS5.6B 5.6V 5.49TO5.
ZD408 0DZ560009DA "Diode,Zener" UDZS5.6B 5.6V 5.49TO5.
ZD409 0DZ560009DA "Diode,Zener" UDZS5.6B 5.6V 5.49TO5.
ZD415 0DZ360009EB "Diode,Zener" UDZS3.6B 3.6V 3.6TO3.8
ZD416 0DZ560009DA "Diode,Zener" UDZS5.6B 5.6V 5.49TO5.
ZD417 0DZ560009DA "Diode,Zener" UDZS5.6B 5.6V 5.49TO5.
ZD418 0DZ560009DA "Diode,Zener" UDZS5.6B 5.6V 5.49TO5.
ZD419 0DZ560009DA "Diode,Zener" UDZS5.6B 5.6V 5.49TO5.
ZD502 0DZRM00248A "Diode,Zener" RLZ8.2B 8.2V 7.78TO8.1
ZD700 0DZ360009EB "Diode,Zener" UDZS3.6B 3.6V 3.6TO3.8
ZD705 0DZ360009EB "Diode,Zener" UDZS3.6B 3.6V 3.6TO3.8
ZD710 0DZ560009DA "Diode,Zener" UDZS5.6B 5.6V 5.49TO5.
ZD711 0DZ360009EB "Diode,Zener" UDZS3.6B 3.6V 3.6TO3.8
ZD712 0DZ360009EB "Diode,Zener" UDZS3.6B 3.6V 3.6TO3.8
IC402 0IPRP00696E "IC,A/D Converter" MST3361MS-LF-170 3.3V_
IC403 EAN32724701 "IC,Analog Switch" STMAV335 4.0TO5.5V 5NS
IC409 EAN35942401 "IC,Analog Switch" TMDS341APFCR 3TO3.6V 1
IC505 EAN32404601 "IC,Audio Amplifier" NTP3000 7TO30V 5.5V 0.
IC201 EAN33931901 "IC,CMOS" TC74LCX16373AFT 2V~3.6
IC202 EAN33931901 "IC,CMOS" TC74LCX16373AFT 2V~3.6
IC305 0ISTLPH026A "IC,CMOS" 74LVC14APW 1.2TO3.6V 0
IC712 EAN32013101 "IC,DC,DC Converter" MIC2505-2YM 2.7V TO 7.
IC200 EAN33624401 "IC,DDR2 SDRAM" HYB18TC512160BF-3S 512
IC203 EAN33624401 "IC,DDR2 SDRAM" HYB18TC512160BF-3S 512
IC206 EAN33624401 "IC,DDR2 SDRAM" HYB18TC512160BF-3S 512
IC208 EAN33624401 "IC,DDR2 SDRAM" HYB18TC512160BF-3S 512
IC207 0IMCRAL021A "IC,EEPROM" AT24C512W-10SU-2.7 512
IC310 0IMCRAL006A "IC,EEPROM" AT24C16AN-10SU-2.7 16K
IC404 0IMMRCS012B "IC,EEPROM" CAT24C08W-T(MST3000) 8
IC405 0IMMRAL014D "IC,EEPROM" AT24C02BN-SH-T 2KBIT 2
IC406 0IMMRAL014D "IC,EEPROM" AT24C02BN-SH-T 2KBIT 2
LOC. NO. PART NO. DESCRIPTION / SPECIFICATION LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
Copyright © 2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
DIODEs
ICs
