LG 47LB9DF - Page 60

- 60 -
R787 0RJ1502C478 "Resistor,Chip" MCR01MZPF153 15KOHM 1%
R8027 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1
R9009 0RJ0222C678 "Resistor,Chip" MCR01MZPJ220 22OHM 5%
R9010 0RJ0222C678 "Resistor,Chip" MCR01MZPJ220 22OHM 5%
R9011 0RJ0222C678 "Resistor,Chip" MCR01MZPJ220 22OHM 5%
R9012 0RJ0222C678 "Resistor,Chip" MCR01MZPJ220 22OHM 5%
R9014 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1
R9016 0RJ0222C678 "Resistor,Chip" MCR01MZPJ220 22OHM 5%
R9016 0RJ0471C678 "Resistor,Chip" MCR01MZPJ4R7 4.7OHM 5%
R9017 0RJ0222C678 "Resistor,Chip" MCR01MZPJ220 22OHM 5%
R9017 0RJ0471C678 "Resistor,Chip" MCR01MZPJ4R7 4.7OHM 5%
R9018 0RJ0822C678 "Resistor,Chip" MCR01MZPJ820 82OHM 5%
R9020 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1
R9022 0RJ0222C678 "Resistor,Chip" MCR01MZPJ220 22OHM 5%
R9023 0RJ0222C678 "Resistor,Chip" MCR01MZPJ220 22OHM 5%
R9024 0RJ3301C678 "Resistor,Chip" MCR01MZPJ332 3.3KOHM 5
R9027 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1
R9028 0RJ0222C678 "Resistor,Chip" MCR01MZPJ220 22OHM 5%
R9029 0RJ1202C678 "Resistor,Chip" MCR01MZPJ123 12KOHM 5%
R9030 0RJ1002C678 "Resistor,Chip" MCR01MZPJ103 10KOHM 5%
R9031 0RJ8201C478 "Resistor,Chip" MCR01MZPF8201 8.2KOHM
R9033 0RJ4700C678 "Resistor,Chip" MCR01MZPJ471 470OHM 5%
R9034 0RJ1001C678 "Resistor,Chip" MCR01MZPJ102 1KOHM 5%
R9035 0RJ3300C678 "Resistor,Chip" MCR01MZPJ331 330OHM 5%
R9036 0RJ1002C678 "Resistor,Chip" MCR01MZPJ103 10KOHM 5%
R9038 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1
R9080 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1
R9083 0RJ0752C678 "Resistor,Chip" MCR01MZPJ750 75OHM 5%
R9084 0RJ1000C678 "Resistor,Chip" MCR01MZPJ101 100OHM 5%
R9085 0RJ1500C678 "Resistor,Chip" MCR01MZPJ151 150OHM 5%
R9086 0RJ1001C678 "Resistor,Chip" MCR01MZPJ102 1KOHM 5%
R9087 0RJ1500C678 "Resistor,Chip" MCR01MZPJ151 150OHM 5%
R9088 EBC32174201 "Resistor,Chip" MCR01MZP5J112 1.1KOHM
R9089 0RJ1000C678 "Resistor,Chip" MCR01MZPJ101 100OHM 5%
R9090 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1
R9091 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1
R9094 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1
R9095 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1
X100 EAW30352304 Crystal 9C55400023(16pf) 55.47
X300 6202TST001E Crystal SX-1 24MHZ 30PPM(20PF)
X400 6202VDT002B Crystal SX-1 14.31818MHZ 30PPM
X500 6202VDT002H Crystal SX-1 18.432MHZ 30PPM(1
J101 6612J10033A "Jack,Complex" PMJ016-13 13P DIN/RCA
JK705 6612J00062H "Jack,Complex" PMJ029-01 14P DIN/RCA
JK9000 6612J10025A "Jack,Complex" KCN-BT-0-0055 4P PAL/R
JK402 6612B00015B "Jack,DIN" DC1R019WDH SOCKET 21P
JK403 6612B00015B "Jack,DIN" DC1R019WDH SOCKET 21P
JK404 6612B00015B "Jack,DIN" DC1R019WDH SOCKET 21P
J1 EAG32151101 "Jack,Fiber Optic" "TOX177L(F,T) 3P TX 2.5"
JK702 6612F00099A "Jack,Phone" PEJ024-01 1P 4P STRAIG
JK703 6612F00099A "Jack,Phone" PEJ024-01 1P 4P STRAIG
JK400 6612J10031A "Jack,RCA" PPJ209-02 14.0MM 1RX5C
JK401 6612J10031A "Jack,RCA" PPJ209-02 14.0MM 1RX5C
JK704 6612J10043A "Jack,RCA" PPJ200-07 15MM 1RX4C A
LD700 0DL233309AC "LED,Chip" SAM2333 RED/Y-GREEN 2.
LD701 0DL233309AC "LED,Chip" SAM2333 RED/Y-GREEN 2.
LD702 0DL233309AC "LED,Chip" SAM2333 RED/Y-GREEN 2.
LD9002 0DL233309AC "LED,Chip" SAM2333 RED/Y-GREEN 2.
LED1 0DLBE0138AA "LED,DIP" BL-BUBGE301 ROUND 3MM
IC205 SAA30964906 "S/W,Firmware" V3.06.0 708b AUSTRALIA
IC309 SAA30775804 "S/W,Firmware" V3.00 86B9 AUSTRALIA Q
SW101 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC
SW102 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC
SW103 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC
SW104 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC
SW105 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC
SW106 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC
SW107 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC
SW108 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC
SW300 6600VR1004A "Switch,Tact" SKHMPWE010 1C1P 12VDC
VR400 6102W5V016A Varistor AVRL161A1R1NT 10V 30%
VR401 6102W5V016A Varistor AVRL161A1R1NT 10V 30%
VR402 6102W5V016A Varistor AVRL161A1R1NT 10V 30%
VR403 6102W5V016A Varistor AVRL161A1R1NT 10V 30%
VR404 6102W5V016A Varistor AVRL161A1R1NT 10V 30%
VR405 6102W5V016A Varistor AVRL161A1R1NT 10V 30%
VR406 6102W5V016A Varistor AVRL161A1R1NT 10V 30%
VR407 6102W5V016A Varistor AVRL161A1R1NT 10V 30%
VR408 6102W5V016A Varistor AVRL161A1R1NT 10V 30%
VR409 6102W5V016A Varistor AVRL161A1R1NT 10V 30%
VR410 6102W5V016A Varistor AVRL161A1R1NT 10V 30%
VR411 6102W5V016A Varistor AVRL161A1R1NT 10V 30%
C16 68509A0004E "Cable,Assembly" RCA JACK RCA JACK 1.0M
JK300 6630G00001C "Connector,DSUB" KCN-DS-1-0088 D-SUB 9P
JK405 6630TGA004K "Connector,DSUB" KCN-DS-1-0089 D-SUB 15
P103 6630SK00604 "Connector,USB" UAR27-4K2300 A 1P 2.50
C2 6630V90142A "Connector,Wafer" TPH254-R-1419-6A 6P 2.
P102 6602T20008N "Connector,Wafer" SMW200-14P 14P 2.00MM
P102 6602T20009C "Connector,Wafer" SMAW200-04P 4P 2.00MM
P102 6602T20009C "Connector,Wafer" SMAW200-04P 4P 2.00MM
P103 6602T20009L "Connector,Wafer" SMAW200-12P 12P 2.00MM
P104 6602T25008B "Connector,Wafer" SMW250-03P 3P 2.50MM 1
P105 6602T20008D "Connector,Wafer" SMW200-05P 5P 2.00MM 1
P501 6602T25008C "Connector,Wafer" SMW250-04P 4P 2.50MM 1
P502 6602T25008B "Connector,Wafer" SMW250-03P 3P 2.50MM 1
P600 6630V93270A "Connector,Wafer" FI-RE51S-HFK-A 51P 0.5
P700 6602T20008N "Connector,Wafer" SMW200-14P 14P 2.00MM
P701 6602T25008M "Connector,Wafer" SMW250-13P 13P 2.50MM
P702 6602T25008J "Connector,Wafer" SMW250-10P 10P 2.50MM
P703 6602T20008L "Connector,Wafer" SMW200-12P 12P 2.00MM
P712 6602T20008D "Connector,Wafer" SMW200-05P 5P 2.00MM 1
C1 5240T0F004A "Harness,Single" LEAD SET 100MM 385-09
C10 6631T20032B "Harness,Single" PHR-12P PHR-12P 600mM
C11 6631T20032V "Harness,Single" INVERTER 12P(2.0MM) PH
C12 6631T20032W "Harness,Single" 12-12(1050MM) PHR-12P
LOC. NO. PART NO. DESCRIPTION / SPECIFICATION LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
Copyright © 2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
CONNECTOR
OTHERs
