LG 47LB9DF - Page 9

Copyright © 2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
- 9 -
6. Component Input (Y, CB
/PB, CR/PR)
7. RGB PC
No. Resolution H-freq(kHz) V-freq(Hz) Pixel clock(MHz) Remark
PC DDC
1 720*400 31.469 70.08 28.32 DOS O
2 640*480 31.469 59.940 25.175 VESA(VGA) O
3 640*480 37.500 75.000 31.500 VESA(VGA) O
4 800*600 37.879 60.317 40.000 VESA(SVGA) O
5 800*600 46.875 75.000 49.500 VESA(SVGA) O
6 1024*768 48.363 60.004 65.000 VESA(XGA) O
7 1024*768 56.476 70.069 75.000 VESA(XGA) O
8 1024*768 60.023 75.029 78.750 VESA(XGA) O
9 1280*768 47.776 59.870 79.500 VESA(WXGA) X
10 1360*768 47.712 60.015 85.500 VESA(WXGA) O
11 1366*768 47.13 59.65 72.00 X
12 1280*1024 63.981 60.020 108.000 VESA(SXGA) O
13 1280*1024 79.976 75.025 135.000 VESA(SXGA) O
14 1600*1200 75.000 60.000 162.000 VESA(UXGA) O
15 1920*1080 67.500 60.000 148.500 HDTV 1080P O
No. Resolution H-freq(kHz) V-freq(Hz) Pixel clock(MHz) Remark
1. 720*576 15.625 50.00 13.50 SDTV576i
2. 720*576 31.25 50.00 27.00 SDTV576p
3. 720*480 15.73/15.75 59.94/60.00 13.50 SDTV 480i
4. 720*480 31.47/31.50 59.94/60.00 27.00 SDTV 480p
5. 1280*720 44.96/45.00 59.94/60.00 74.25 HDTV 720P
6. 1280*720 37.50 50.00 74.25 HDTV 720P
7. 1920*1080 33.72/33.75 59.94/60.0 74.25 HDTV 1080i
8. 1920*1080 28.125 50.00 74.25 HDTV 1080i
9. 1920*1080 26.97/27.00 23.976/24.00 74.1757/74.25 HDTV 1080P
10. 1920*1080 33.716/33.750 29.97/30.00 74.1762/74.25 HDTV 1080P
11. 1920*1080 56.25 50.00 148.50 HDTV 1080P
12. 1920*1080 67.43/67.50 59.94/60.00 148.50 HDTV 1080P
