LG 50PC5D - Page 34

- 35 -
R982 0RJ0000C678 "Resistor,Chip" MCR01MZPJ000 0OHM 5% 1
IC101 SAA31495603 "S/W,Firmware" 3.01 9C1C NORTH AMERIC
IC903 0IPRPNS054A "Sensor,Temperature" LM75CIMX-3 3TO5.5V SOP
SW101 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC
SW102 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC
SW103 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC
SW104 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC
SW105 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC
SW106 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC
SW107 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC
SW108 140-313B "Switch,Tact" KPT-1115AM 1C1P 12VDC
SW400 6600VR1004A "Switch,Tact" SKHMPWE010 1C1P 12VDC
TU1 EBL39544401 "Tuner,Analog/Digital" TDVR-H651F NTSC/ATSC 5
VR600 6102W5V016A Varistor AVRL161A1R1NT 10V 30%
VR601 6102W5V016A Varistor AVRL161A1R1NT 10V 30%
VR604 6102W5V016A Varistor AVRL161A1R1NT 10V 30%
VR605 6102W5V016A Varistor AVRL161A1R1NT 10V 30%
VR606 6102W5V016A Varistor AVRL161A1R1NT 10V 30%
VR607 6102W5V016A Varistor AVRL161A1R1NT 10V 30%
X200 6212AA2600B Crystal 54MHz 54MHZ 30PPM 10pF
X400 6202TST001E Crystal SX-1 24MHZ 30PPM(20PF)
JK701 EAG35541101 "Jack,Complex" PMJ029-07 14P DIN/RCA
JK601 6612B00015B "Jack,DIN" DC1R019WDH SOCKET 21P
JK602 6612B00015B "Jack,DIN" DC1R019WDH SOCKET 21P
JK501 EAG37842001 "Jack,Fiber Optic" JST1223-001 5P TX 9.80
JK703 6612F00099A "Jack,Phone" PEJ024-01 1P 4P STRAIG
P402 6612F00099A "Jack,Phone" PEJ024-01 1P 4P STRAIG
JK700 EAG35540801 "Jack,RCA" PPJ209-03 14.0MM 1RX5C
JK702 EAG35540801 "Jack,RCA" PPJ209-03 14.0MM 1RX5C
JK704 EAG35541501 "Jack,RCA" PPJ200-08 14.0mm 1RX2C
LD803 0DL233309AC "LED,Chip" SAM2333 RED/Y-GREEN 2.
D1 0DL200000CA "LED,DIP" SAM5670(DL-2LRG) ROUND
C8 6852TAZ010F "Cable,Assembly" KCN-NS-0-0038 SMA CONN
JK705 6630G70016A "Connector,DSUB" A03-7071-094 D-SUB 15P
P400 6630G70017A "Connector,DSUB" A02-0915-101 D-SUB 9P
P201 EAG31022001 "Connector,USB" UB01123-4HHS-4F A 1P 2
P101 6602T20009E "Connector,Wafer" SMAW200-06P 6P 2.00MM
P101 6602T20009L "Connector,Wafer" SMAW200-12P 12P 2.00MM
P102 6602T20008N "Connector,Wafer" SMW200-14P 14P 2.00MM
P102 6602T20009E "Connector,Wafer" SMAW200-06P 6P 2.00MM
P1506 6602T12004C "Connector,Wafer" 12505WS-04A00 4P 1.25M
P200 6602T25008C "Connector,Wafer" SMW250-04P 4P 2.50MM 1
P401 6602T20008L "Connector,Wafer" SMW200-12P 12P 2.00MM
P500 6602T25009C "Connector,Wafer" SMAW250-04P 4P 2.50MM
P700 6602T20008N "Connector,Wafer" SMW200-14P 14P 2.00MM
P705 6602T12004C "Connector,Wafer" 12505WS-04A00 4P 1.25M
P800 6602T25008J "Connector,Wafer" SMW250-10P 10P 2.50MM
P801 6602T25008M "Connector,Wafer" SMW250-13P 13P 2.50MM
P901 6630V90116A "Connector,Wafer" FI-X30SSL-HF 30P 1.00M
P904 366-932B "Connector,Wafer" GIL-G-03P-S3T2-E(TYPOE
P905 366-932B "Connector,Wafer" GIL-G-03P-S3T2-E(TYPOE
C1 6631900010F "Harness,Single" SMH200-12P SMH200-12P
C2 6631900012E "Harness,Single" SMH250 SMH250 300mM 2.
C3 6631900027E "Harness,Single" SMH250 SMH250 300mM 2.
C4 6631900108B "Harness,Single" SMH200 SMH200 700mM 2.
C5 6631V12031F "Harness,Single" 12505HS-0400 12505HS-0
C6 6631V39015F "Harness,Single" GP390-04S-CS 1-1123722
C7 6631V39016E "Harness,Single" GP390-10S-CS 1-1123722
C9 EAD36175301 "Harness,Single" SMH200 SMH200 1200MM 2
C10 EAD39752801 "Harness,Single" 4P(SPK_LEFT/RIGHT) SMH
LOC. NO. PART NO. DESCRIPTION / SPECIFICATION LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
OTHERs
CONNECTOR
