- 4 -

Only for training and service purposes

SPECIFICATION

NOTE : Specifications and others are subject to change without notice for improvement

4. Module General Specification

1. Application range

This specification is applied to the LCD TV used LB03R

chassis.

2. Requirement for Test

Each part is tested as below without special appointment.

1) Temperature: 25 ºC ± 5 ºC(77 ºF ± 9 ºF), CST: 40 ºC ± 5 ºC

2) Relative Humidity : 65 % ± 10 %

3) Power Voltage

: Standard input voltage (AC 100-240 V~ 50 / 60 Hz)

* Standard Voltage of each products is marked by models.

4) Specification and performance of each parts are followed

each drawing and specification by part number in

accordance with BOM.

5) The receiver must be operated for about 5 minutes prior to

the adjustment.

3. Test method

1) Performance: LGE TV test method followed

2) Demanded other specification

- Safety : CE, IEC specification

- EMC :CE, IEC

No. Item Specification Remark

1 Display Screen Device 139 cm(55 inch) wide color display module

2 Aspect Ratio 16:9

3 LCD Module 139 cm(55 inch) TFT LCD FHD 240 Hz(Edge)

4 Operating Environment Temp. : 0 deg ~ 50 deg

Humidity : 20 % ~ 90 %

5 Storage Environment Temp. : -20 deg ~ 60 deg

Humidity : 10 ~ 90 %

6 Input Voltage AC 100-240V~, 50 / 60Hz

7 Power Consumption Power on (White) LCD (Module) + Backlight(EDGE LED)

LGD Edge Typ : 154.2

8 Module Size 1261.6 (H) x 732.4 (V) x 24.2 mm(D)

8 Pixel Pitch 0.630 (H) x 0.630 (V)

9 Back Light LED(Edge)

10 Display Colors 1.06 B(true) colors

11 Coating 3H
