LG 60UJ6540 - Power Distribution Network

- 12 -
Copyright © LG Electronics Inc. All rights reserved.
Only for training and service purposes.
3. Power
LDO DCDC
+
D13V
+5V_NORMAL
IC1600 / 4A IC1400 / 3A
Q1100
IC1700 / 4A
AUDIO AMP
DDR3
+
3.3V_NORMAL
+3.5V_ST
+1.8V_IO
IC2100 / 3A
+0.9V_CPU
IC2000 / 10A
+0.9V_CORE
+A13V
USB1 (2.0)
USB2 (2.0)
PANEL
IC1500 / 3.5A
S
Y8823
1.5V_DDR
MICOM
IR_KEY
ETHERNET
WIFI
+3.5V_WOL
WIFI_EN
CPU_1V0
MAIN IC
Main
IC6900 / 2A
IC1800 / 3A
SWITCH
+0.9V_DDR
MAIN IC
NVRAM
H/ P AMP
1.2V_DEMOD
TUNER
AUDIO AMP
MAX3232CDR
IC2200 / 2A IC2300 / 2A
+AVDDT_EPI_C4TX
MAIN IC
MAIN IC
