LG AMNH07GD4L0 User Manual

214 Multi type Air Conditioner
Exploded View & Replacement Parts List
Parts List (SQ, SR chassis)
PART No.
AMNH076LQL0 AMNH096LQL0 AMNH096LRL0 AMNH126LRL0
131410 CHASSIS ASSEMBLY 3141A20006A 3141A20006A 3141A20005A 3141A20005A R
135311 GRILLE ASSEMBLY,DISCHARGE(INDOOR) 3531A10127A 3531A10127A 3531A10230A 3531A10230A R
135314 GRILLE ASSEMBLY,INLET SUB 3531A20100B 3531A20100B 3531A10117B 3531A10117B R
135316
GRILLE ASSEMBLY,FRONT(INDOOR)
3531A20187M 3531A20187M 3531A10208N 3531A10208N R
135516 COVER ASSEMBLY,MOTOR 3551A20050P 3551A20050P 3551A20099A 3551A20099A R
146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A 4681A20055A 4681A20055A R
152302 FILTER(MECH),A/C 5230A10005A 5230A10005A 5230A20014C 5230A20014C R
152313 FILTER ASSEMBLY,DEODORIZER 5231A20032C 5231A20032C 5231A20032C 5231A20032C R
159830 AIR CLEANER ASSEMBLY 5983A10009V 5983A10009V 5983A10006V 5983A25001J R
159901 VANE,HORIZONTAL 5990A10005A 5990A10005A 5990A20007A 5990A20007A R
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A20361A 4995A20361B 4995A20361C 4995A20361D R
263230-1 THERMISTOR ASSEMBLY 6323AQ3226T 6323AQ3226T 3623AQ3226T 3623AQ3226T R
263230-2 THERMISTOR ASSEMBLY 6323A20004A 6323A20004A 6323A20004A 6323A20004A R
266090 H.V ASSEMBLY 6609A10003J 6609A10003J 6609A10003H 6609A10003H R
267110 REMOTE CONTROLLER ASSEMBLY 6711A20067J 6711A20067J 6711A20067J 6711A90022J R
268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A20194A 6871A20194A 6871A20390A 6871A20390A R
268715 PWB(PCB) ASSEMBLY,MAIN(AC) 6871A20267B 6871A20267B 6871A20267B 6871A20267B R
268716 PWB(PCB) ASSEMBLY,MAIN(DC) 6871A20440A 6871A20440B 6871A20440C 6871A20440D R
342800 BEARING 4280A20004A 4280A20004A 4280A20004A 4280A20004A R
346810 MOTOR ASSEMBLY,INDOOR 4681A20062A 4681A20062A 4681A20048A 4681A20048A R
35211B TUBE ASSEMBLY,TUBING 5211A21399B 5211A21399B 5211A21400F 5211A21400F R
352115 TUBE ASSEMBLY,EVAPORATOR IN 5211A20470J 5211A20470J 5211A20388H 5211A20388H R
352116 TUBE ASSEMBLY,EVAPORATOR OUT 5211A20471D 5211A20471D 5211A20389F 5211A20389F R
352150 HOSE ASSEMBLY,DRAIN 5251AR2575F 5251AR2575F 5251AR2575F 5251AR2575F R
354210 EVAPORATOR ASSEMBLY, FIRST 5421A10024A 5421A10024A 5421A20086A 5421A20086A R
359011 FAN ASSEMBLY,CROSS FLOW 5901A20007B 5901A20007B 5901A20007A 5901A20007D R
733010 PLATE ASSEMBLY,INSTALL 3301A10003A 3301A10003A 1H00843A 1H00843A R
W0CZZ CAPACITOR,DRAWING 3H01487A 3H01487A 3H1487A 3H1487A R
DESCRIPTION
SVC
CODE
LOCATION
No.
