218 Multi type Air Conditioner

Exploded View & Replacement Parts List

PartsList(S4,S5chassis)

PART No.

AMNH07GD4L0 AMNH09GD4L0 AMNH12GD4L0 AMNH18GD5L0 AMNH24GD5L0

131410 CHASSIS ASSEMBLY 3141A20019C 3141A20019C 3141A20019C 3141A20020B 3141A20020B R

135311

GRILLE ASSEMBLY,DISCHARGE(INDOOR)

3531A10307A 3531A10307A 3531A10307A 3531A20252T 3531A20252T R

135314 GRILLE ASSEMBLY,INLET SUB 3531A10312A 3531A10312A 3531A10312A 3531A20254A 3531A20254A R

135316 GRILLE ASSEMBLY,FRONT(INDOOR) 3531A14002Z 3531A14002Z 3531A14002Z 3531A20299D 3531A20299D R

135516 COVER ASSEMBLY,MOTOR 3551A20156B 3551A20156B 3551A20156B 3551A20154B 3551A20154B R

146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A 4681A20055A 4681A20055A 4681A20055A R

152302 FILTER(MECH),A/C 5230A20051B 5230A20051D 5230A20051B 5230A20052B 5230A20052B R

152313 FILTER ASSEMBLY,DEODORIZER 5231A20040A 5231A20040A 5231A20040A 5231A20040B 5231A20040B R

159830 AIR CLEANER ASSEMBLY 5983A20017A 5983A20017A 5983A20017A 5983A20018A 5983A20018A R

159901 VANE,HORIZONTAL 5990A20069A 5990A20069A 5990A20069A 5990A20071A 5990A20071A R

249951 CONTROL BOX ASSEMBLY,INDOOR 4995A20632A 4995A20632B 4995A20632C 4995A20632D 4995A20632E R

263230-1 THERMISTOR ASSEMBLY 6323AQ3226T 6323AQ3226T 6323AQ3226T 6323AQ3226T 6323AQ3226T R

263230-2 THERMISTOR ASSEMBLY 6323A20004A 6323A20004A 6323A20004A 6323A20004A 6323A20004A R

266090 H.V ASSEMBLY 6609A10003Z 6609A10003Z 6609A10003Z 6609A10008A 6609A10008A R

267110 REMOTE CONTROLLER ASSEMBLY 6711A20107C 6711A20107C 6711A20107C 6711A20107C 6711A20107C R

268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A20574A 6871A20574A 6871A20574A 6871A20624A 6871A20624A R

268714 PWB(PCB) ASSEMBLY,MAIN 6871A20156J 6871A20156K 6871A20156L 6871A20156M 6871A20156N R

342800 BEARING 4280A20004B 4280A20004B 4280A20004B 4280A20004A 4280A20004A R

346810 MOTOR ASSEMBLY,INDOOR 4681A20091J 4681A20091J 4681A20091J 4681A20091J 4681A20091J R

35211B TUBE ASSEMBLY,TUBING 5211A21363E 5211A21363E 5211A21363E 5211A21378G 5211A21378G R

352150 HOSE ASSEMBLY,DRAIN 5251A20011B 5251A20011D 5251A20011D 5251A20011D 5251A20011D R

354210 EVAPORATOR ASSEMBLY,FIRST 5421A20218A 5421A20218A 5421A20218A 5421A20220A 5421A20220A R

359011 FAN ASSEMBLY,CROSS FLOW 5901A20071F 5901A20071F 5901A20017F 5901A92441E 5901A92441E R

733010 PLATE ASSEMBLY,INSTALL 3301A20020C 3301A20020C 3301A20020C 3301A20020B 3301A20020B R

135500 COVER 3550A21008A 3550A21008A 3550A21008A 3550A21008A 3550A21008A R

DESCRIPTION

SVC

CODE

LOCATION

No.
