220 Multi type Air Conditioner
Exploded View & Replacement Parts List
Parts List (SP1 chassis)
PART No.
AMNH096AP*1 AMNC096AP*1 AMNH126AP*1 AMNC126AP*1
131410 CHASSIS ASSEMBLY 3141A20004N 3141A20004N 3141A20004N 3141A20004N R
135500-1 COVER 3550A20123A 3550A20123A 3550A20123A 3550A20123A R
135500-2 COVER 3550A20124A 3550A20124A 3550A20124A 3550A20124A R
135500-3 COVER 3550A20060A 3550A20060A 3550A20060A 3550A20060A R
135311-1
GRILLE ASSEMBLY,DISCHARGE(INDOOR)
3531A20069G 3531A20069G 3531A20069G 3531A20069G R
135311-2
GRILLE ASSEMBLY,DISCHARGE(INDOOR)
3531A20069H 3531A20069H 3531A20069H 3531A20069H R
135311-3
GRILLE ASSEMBLY,DISCHARGE(INDOOR)
3531A20069J 3531A20069J 3531A20069J 3531A20069J R
135314
GRILLE ASSEMBLY, M: Matal
3531A20212K 3531A20212K 3531A20212K 3531A20212K R
INLET
B:
Blue
3531A20212L 3531A20212L 3531A20212L 3531A20212L R
D:
Wood
3531A20212M 3531A20212M 3531A20212M 3531A20212M R
135515 COVER ASSEMBLY,TOP(INDOOR) 3551A20031B 3551A20031B 3551A20031B 3551A20031B R
135316 GRILLE ASSEMBLY,
M: Matal
3531A20213N 3531A20213R 3531A20213N 3531A20213R R
FRONT(INDOOR) B: Blue 3531A20213P 3531A20213S 3531A20213P 3531A20213S R
D: Wood 3531A20213Q 3531A20213T 3531A20213Q 3531A20213T R
147581 LOUVER,HORIZONTAL 4758A20014B 4758A20014B 4758A20014B 4758A20014B R
146811-1 MOTOR ASSEMBLY,STEP 4681A20055C 4681A20055C 4681A20055C 4681A20055C R
146811-2 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A 4681A20055A 4681A20055A R
152302 FILTER(MECH),A/C 5230A20032A 5230A20032A 5230A20032A 5230A20032A R
159830 AIR CLEANER ASSEMBLY 5983A20007F 5983A20007F 5983A20007F 5983A20007F R
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A20372H 4995A20372N 4995A20372J 4995A20372P R
249941 CONTROL BOX,INDOOR 4994A10046A 4994A10046A 4994A10046A 4994A10046A R
268715 PWB(PCB) ASSEMBLY,MAIN(AC) 6871A20380D 6871A20380D 6871A20380D 6871A20380D R
268716 PWB(PCB) ASSEMBLY,MAIN(DC) 6871A20381D 6871A20381G 6871A20381F 6871A20381G R
266090 H.V ASSEMBLY 6609A10003S 6609A10003S 6609A10003S 6609A10003S R
263230-1 THERMISTOR ASSEMBLY 6323AQ3226T 6323AQ3226T 6323AQ3226T 6323AQ3226T R
263230-2 THERMISTOR ASSEMBLY 6323A20004N 6323A20004N 6323A20004N 6323A20004N R
268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A20388A 6871A20363D 6871A20388A 6871A20363D R
267110 REMOTE CONTROLLER ASSEMBLY 6711A20073D 6711A20073E 6711A90031D 6711A20073E R
330870 DRAIN PAN ASSEMBLY 3087A30004A 3087A30004A 3087A30004A 3087A30004A R
346810 MOTOR ASSEMBLY,INDOOR 4681A20091A 4681A20091A 4681A20091A 4681A20091A R
349600 MOUNT,MOTOR 4960A20016A 4960A20016A 4960A20016A 4960A20016A R
352116
TUBE ASSEMBLY,EVAPORATOR OUT
5211A20301J 5211A20301J 5211A20301J 5211A20301J R
352115 TUBE ASSEMBLY,EVAPORATOR IN 5211A20302J 5211A20302J 5211A20302J 5211A20302J R
35211B TUBE ASSY,TUBING 5211AR7066F 5211AR7066F 5211AR7066F 5211AR7066F R
352150 HOSE ASSEMBLY,DRAIN 5251AR1222R 5251AR1222R 5251AR1222R 5251AR1222R R
352380 AIR GUIDE 5238A20020A 5238A20020A 5238A20020A 5238A20020A R
354210 EVAPORATOR ASSEMBLY,FIRST 5421A20072A 5421A20072A 5421A20072A 5421A20072A R
359012 FAN,TURBO 5900A00003A 5900A00003A 5900A00003A 5900A00003A R
