224 Multi type Air Conditioner
Exploded View & Replacement Parts List
Parts List(Art cool Deluxe Type BLDC)
PART No.
AMNH07GDZ*0 AMNH09GDU*0 AMNH12GDU*0 AMNH18GD3*0 AMNH24GD3*0
131410 CHASSIS ASSEMBLY 3141A20009B 3141A20007B 3141A20007B 3141A20012A 3141A20012A R
135080-1 DECORATION (TOP) 3508A20055B 3508A20034E 3508A20034E - - R
135080-2 DECORATION (BOTTOM) 3508A20056B 3508A20034F 3508A20034F - - R
135311 GRILLE ASSEMBLY, DISCHARGE 3531A20184C 3531A20137B 3531A20137B 3531A20231C 3531A20231C R
135313 GRILLE ASSEMBLY, INLET
W: White 3531A20196J 3531A10331B 3531A10331B 3531A20244E 3531A20244E R
M: Metal 3531A20196E 3531A10331C 3531A10331C 3531A20244A 3531A20244A R
R: Mirror 3531A20195B 3531A10331A 3531A10331A 3531A20232B 3531A20232B R
B: Blue 3531A20196F 3531A10331D 3531A10331D - - R
135316 GRILLE ASSEMBLY, FRONT
W: White 3531A10214W 3531A21026V 3531A21026V 3531A30032C 3531A30032C R
M: Metal 3531A10214U 3531A21026U 3531A21026U 3531A30032B 3531A30032B R
R: Mirror 3531A10214T 3531A21026T 3531A21026T 3531A30032A 3531A30032A R
B: Blue 3531A10214V 3531A21026W 3531A21026W - - R
146811 MOTOR ASSEMBLY, STEP (Vane) 4681A20055A 4681A20055A 4681A20055A 4681A20055A 4681A20055A R
146811-1 MOTOR ASSEMBLY, STEP (Door) 4681A20055B 4681A20055B 4681A20055B 4681A20055D 4681A20055D R
159830 AIR CLEANER ASSEMBLY 5983A10009V 5983A25003H 5983A25003H 5983A25004J 5983A25004J R
152302 FILTER (MECH), A/C 5230A20033A 5230A20022A 5230A20022A 5230A20047A 5230A20047A R
159901 VANE, HORIZONTAL 5990A20022B 5990A20015B 5990A20015B 5990A20042B 5990A20042B R
249951 CONTROL BOX ASSEMBLY 4995A20637A 4995A20637B 4995A20637C 4995A20637D 4995A20637E R
249941 CONTROL BOX, INDOOR 4994A20067A 4994A20067A 4994A20067A 4994A20067A 4994A20067A R
263020 LCD 6306A90005A 6306A90005A 6306A90005A 6306A90005A 6306A90005A R
263230-1 THERMISTOR ASSEMBLY (Out) 6323A3226T 6323A3226T 6323A3226T 6323AQ3226T 6323AQ3226T R
263230-2 THERMISTOR ASSEMBLY (Room, in) 6323A20004A 6323A20004A 6323A20004A 6323A20004A 6323A20004A R
266090 HUB ASSEMBLY 6609A10005B 6609A10005D 6609A10005D 6609A10005D 6609A10005D R
267110 REMOE CONTROLLER ASSEMBLY 6711A20107D 6711A20107C 6711A20107C 6711A20107C 6711A20107C R
268714 PWB(PCB) ASSEMBLY, MAIN 6871A20799A 6871A20799B 6871A20799C 6871A20799D 6871A20799E R
342800 BEARING 4280A20004A 4280A20004A 4280A20004A 4280A20004A 4280A20004A R
346810 MOTOR ASSEMBLY, INDOOR 4681A20091J 4681A20091J 4681A20091J 4681A20091J 4681A20091J R
352114 TUBE ASSEMBLY, DISTRIBUTOR 5211A20569D 5211A20569D 5211A20569D 5211A14007A 5211A14007A R
352118 TUBE ASSEMBLY MANIFOLD 5211A20605B 5211A20605B 5211A20605B 5211A10474D 5211A10474D R
35211B TUBE ASSEMBLY, TUBING 5211A30596A 5211AR7066L 5211AR7066L 5211A30038Z 5211A30038Z R
352150 HOSE ASEMBLY, DRAIN 5251AR1222R 5251AR1222R 5251AR1222R 5251AR1222R 5251AR1222R R
354212 EVAPORATOR ASSEBLY, FINAL 5421A20149E 5421A20105H 5421A20105H 5421A21004T 5421A21004T R
359011 FAN ASSEMBLY, CROSS FLOW 5901A20016E 5901A20016J 5901A20016J 5901A20017C 5901A20017C R
668713 PWB ASSEMBLY, SUB 6871A20258B 6871A20258B 6871A20258B 6871A20258B 6871A20258B R
668713 PWB ASSEMBLY, SUB 6871A20259A 6871A20259A 6871A20259A 6871A20259A 6871A20259A R
733010 PLATE 3301A10005A 1H00843A 1H00843A 3301A10002A 3301A10002A R
135500 COVER 3550A21008C 3550A21008D 3550A21008D 3550A21008A 3550A21008A R
145200-1 Link 4520A20008A 4520A20008A 4520A20008A 4520A20008A 4520A20008A R
145200-2 Link 4520A20009A 4520A20009A 4520A20009A 4520A20009A 4520A20009A R
DESCRIPTION
SVC
CODE
LOCATION
No.
To Next Page
