Service Manual 261
Exploded View & Replacement Parts List
Outdoor Unit Parts List (Single compressor inverter)
PART No.
A2UW146FA0 A2UW146FA1 A2UW186FA0 A3UW186FA0 A3UW186FA1
137213-1 PANEL ASSEMBLY, SIDE - 1A00201D 1A00201D 1A00201D - R
137213-2 PANEL ASSEMBLY, SIDE - 3A02284M 3A02284M 3A02284M - R
263230-1 THERMISTOR ASSEMBLY (ROOM, OUT) 6323A20020F 6323A20020F 6323A20037A 6323A20037A 6323A20020F R
263230-2 THERMISTOR ASSEMBLY (DISCHARGE, SUCTION) 6323A20020G 6323A20020G 6323A20037B 6323A20037B 6323A20020G R
430411 BASE ASSEMBLY, WELD[OUTDOOR] 3041A20022Q 3041A20022Q 3041A20022Q 3041A20022Q 3041A11002B R
435301 GRILLE, DISCHARGE 3530A20007B 3530A20007J 3530A20007B 3530A20007B 3530A20007B R
435511 COVER ASSEMBLY, CONTROL(OUTDOOR) 3A01919B 3A01919B 3A01919B 3A01919B 3A01919B R
435512 COVER ASSEMBLY, TOP(OUTDOOR) 3H03266K 3H03266L 3H03266L 3H03266L 3H03266K R
437210 PANEL ASSY, FRONT (OUTDOOR) 3721A20005P 3721A20004L 3721A23001A 3721A23001A 3721A30011G R
437212 PANEL ASSEMBY, REAR 3720AP0003F - - - 3720AP0003F R
435300 GRILLE, REAR - 1A00207B 1A00207B 1A00207B - R
447910 BARRIER ASSEMBLY, OUTDOOR 3H03307L 3H03307L 3H03307L 3H03307L 3H03307N R
546810 MOTOR ASSEMBLY, OUTDOOR 4681A20028J 4861A20028S 4681A20028J 4681A20028J 4681A20028J R
548490 ACCUMULATOR ASSEMBLY - - - - 4849A20012E R
552112 TUBE ASSEMBLY, CONDENSER IN 5211A24019A 5211A30298A 5211A30298A 5211A30298A 5211A21423A R
552113-1 TUBE ASSEMBLY, CONDENSER OUT 5211A24018A 5211A30297Z 5211A23320A 5211A23320B 5211A21424A R
552113-2 TUBE ASSEMBLY, COND OUT (SUPPORTER) - 5211A20927A 5211A20927A 5211A21155C 5211A21155E R
552200 VALVE, EXPANSION BODY 5220A90010A - - - - R
552203-1 VALVE, SERVICE (Ø9.52) 5220A20001K 5220A20001K 5220A20001K 5220A20001K 5220A20001K R
552203-2 VALVE, SERVICE (Ø6.35) 2A02479R 2A00468J 2H02479J 2H02479J 2H02479J R
552204-1 COIL ASSEMBLY, EXPANSION (A) 6141A20018K 6877A20050A 6877A20050A 6877A20050A 6877A20050A R
552204-2 COIL ASSEMBLY, EXPANSION(B) 6141A20018L 6877A20050B 6877A20050B 6877A20050B 6877A20050B R
552204-3 COIL ASSEMBLY, EXPANSION (C) - - - 6877A20050C 6877A20050K R
552116 TUBE ASSEMBLY, REVERSING 5211A20493Q 5211A20493U 5211A20493H 5211A20493R 5211A21422A R
554031 CONDENSER ASSEMBLY, BENT 5403A10013J 5403A20072N 5403A20072N 5403A20072N 5403A20072Y R
554160 COMPRESSOR 5416A90008A 5416A90029A 5416A90015A 5416A90015A 2520UGHN2AC R
558511 DRIER ASSEMBLY - 5851A30004A 5851A20003J 5851A20003J - R
559010 FAN ASSEMBLY, PROPELLER 5901A10032A 5901A10032A 5901A10032A 5901A10032A 5901A10032A R
561410 COIL ASSEMBLY, REVERSING VALVE 6141AR3509L 6141AR3509L 6141AR3509L 6141AR3509L 6141AR3509L R
561411 COIL ASSEMBLY, EXPANSION 6140A90001F 6140A90001K 6140A90001K 6140A90001K 6140A90001K R
566000 SWITCH, PRESSURE (LOW PRESSURE) - - 3A02524F 3A02524F - R
649950 CONTROL BOX ASSEMBLY, OUTDOOR 4995A10101H 4995A10101M 4995A10101A 4995A10101J 4995A10101T R
658740 REACTOR 5874A90003E 5874A90003A 5874A90003E 5874A90003E 5874A90003E R
668711 PWB(PCB) ASSEMBLY, MAIN(OUTDOOR) 6871A10117K 6871A10182Y 6871A10117B 6871A10117L 6871A10196B R
668713 PWB(PCB) ASSEMBLY, SUB (CENTRAL CONTROL) 6871A20484A 6871A20484A - - - OPTION
W0CZZ CAPACITOR, DRAWING 2A00986D 2A00986D 2A00986D 2A00986D 2A00986D R
W49810 SUPPORT ASSEMBLY 498110019B - - - - R
