Service Manual 263
Exploded View & Replacement Parts List
Parts List (A3UW246FA0, A4UW246FA0 - TPS Inverter)
137213-1 PANEL ASSEMBLY, SIDE 1A00202F 1A00202F R
137213-2 PANEL ASSEMBLY, SIDE 3A02284R 3A02284T R
263230-1
THERMISTOR ASSEMBY (INV DISCHARGE, SUCTION)
6323A20020G 6323A20020G R
263230-2
THERMISTOR ASSEMBLY (CONST DISCHARGE)
6323A20001J 6323A20001J R
263230-3
THERMISTOR, ASSEMBLY (ROOM, COND OUT)
6323A20020F 6323A20020H R
352113 TUBE, ASSEMBLY, DISCHARGE 5211A23013A 5211A23013A R
430410 BASE ASSEMBLY, WELD 3041AP2741H 3041AP2741H R
435300 GRILLE, REAR 1A00208H 1A00208H R
435301 GRILLE, DISCHARGE 3530A20007J 3530A20007J R
435511 COVER ASSEMBLY, CONTROL (OUTDOOR) 3A01919B 3A01919B R
435512 COVER ASSEMBLY, TOP 3551A30113C 3551A30113C R
437210 PANEL ASSEMBLY, FRONT SUB 1A00197C 1A00197C R
447910 BARRIER ASSEMBLY, OUTDOOR 4791A30004M 4791A30004M R
546810 MOTOR ASSEMBLY, OUTDOOR 4681A20028Y 4681A20028Y R
548490 ACCUMULATOR ASSEMBLY 4849A22003A 4849A22003A R
552111 TUBE ASSEMBLY, CAPILLARY 5211A22009B 5211A22009B R
552113 TUBE ASSEMBLY, CONDENSER OUT 5211A21155B 5211A21155A R
552115 TUBE ASSEMBLY, MANIFOLD 5211A20895A 5211A20895A R
552116 TUBE ASSEMBLY, REVERSING 5211A20896A 5211A20896A R
552203-1 VALVE, SERVICE (Ø9.52) 5220A20001K 5220A20001K R
552203-2 VALVE, SERVICE (Ø6.35) 2H02479J 2H02479J R
552204 VALVE, SOLENOID (BODY) 5220A90002C 5220A90002C R
554031 CONDENSER ASSEMBLY, BENT 5403A20070B 5403A20070B R
554160 COMPRESSOR (INVERTER) 5416A90015A 5416A90015A R
554161 COMPRESSOR (CONSTANT) 5416A90016A 5416A90016A R
558511 DRIER, ASSEMBLY 5851A20003J 5851A20003J R
559010 FAN ASSEMBLY, PROPELLER 5901A10032A 5901A10032A R
561410-1 COIL ASSEMBLY, REVERSING VALVE 6877A20052D 6877A20052D R
561410-2 COIL ASSEMBLY, SOLENOID 6877A20052E 6877A20052E R
561410-3 COIL ASSEMBLY, SOLENOID 6877A20052F 6877A20052F R
561410 VALVE, EXPANSION BODY 6140A90001K 6140A90001K R
561411-1 COIL ASSEMBLY EXPANSION (A) 6877A20050C 6877A20050C R
561411-2 COIL ASSEMBLY EXPANSION (B) 6877A20050D 6877A20050D R
561411-3 COIL ASSEMBLY EXPANSION (C) 6877A20050E 6877A20050E R
561411-4 COIL ASSEMBLY EXPANSION (D) - 6877A20050L R
566000 SWITCH, PRESSURE 3A02524F 3A02524F R
649950 CONTROL BOX ASSEMBLY, OUTDOOR 4995A10101B 4995A10101K R
658740 REACTOR 5874A90003E 5874A90003E R
668711 PWB(PCB) ASSEMBLY, MAIN(OUTDOOR) 6871A10117C 6871A10117M R
552201 VALVE, CHECK 5220A30004A 5220A30004A R
W0CZZ-1 CAPACITOR, DRAWING (FAN) 2A00986D 2A00986D R
W0CZZ-2 CAPACITOR, DRAWING (COMP) 2H00841F 2H00841F R
Location
No.
Description
Part No.
A3UW246FA0 A4UW246FA0
SVC CODE
To Next Page
