Service Manual 265
Exploded View & Replacement Parts List
Parts List (A4UW306FA0, A4UW306FA1 - TPS Inverter)
135301 GRILLE,DISCHARGE 3530A20006G 3530A20006G R
137213-1 PANEL ASSEMBLY,SIDE 3721A10110A 3721A10110A R
137213-2 PANEL ASSEMBLY,SIDE 3721A10111A 3721A10111B R
263230-1 THERMISTOR ASSEMBLY (ROOM, COND, OUT) 6323A20020H 6323A20020H R
263230-2 THERMISTOR ASSEMBLY (DISCHARGE, SUCTION) 6323A20020J 6323A20020J R
263230-3 THERMISTOR ASSEMBLY (DISCHARGE, CONST) 6323A20001K 6323A20001K R
352113 TUBE ASSEMBLY, DISCHARGE SINGLE 35211A23013A AJR31536901 R
430410 BASE ASSEMBLY, OUTDOOR 3041AP2741H 3041AP2741H R
435300 GRILLE,REAR 3530A10176B 3530A10176B R
435511 COVER ASSEMBLY,CONTROL(OUTDOOR) 3A01919B 3A01919B R
435512 COVER ASSEMBLY,TOP(OUTDOOR) 3551A30113D 3551A30113D R
437211 PANEL ASSEMBLY,FRONT(OUTDOOR) 3721A10109A 3721A10109A R
447910 BARRIER ASSEMBLY,OUTDOOR 4791A10019A 4791A10019A R
546810-1 MOTOR ASSEMBLY,OUTDOOR 4681AR1392Y 4681AR1392Y R
546810-2 MOTOR ASSEMBLY, OUTDOOR 4681AR1392Z 4681AR1392Z R
548490 ACCUMULATOR ASSEMBLY(MECH) 4849A22003A AAB31540601 R
552111 TUBE ASSEMBLY, CAPILLARY 5211A22010A AJR31512901 R
552113 TUBE ASSEMBLY, CONDENSER OUT 5211A21155A AJR31515101 R
552115 TUBE ASSEMBLY, MANIFOLD 5211A20895H AJR31513201 R
552116 TUBE ASSEMBLY,REVERSING 5211A20896A AJR31512701 R
552201 VALVE, CHECK 5220A30004A 5220A30004A R
552203-1 VALVE,SERVICE(_9, 52) 5220A20001K 5220A20013A R
552203-2 VALVE,SERVICE (_6, 35) 2H02479J 5220A20007A R
552204 VALVE, SOLENOID (BODY) 5220A90002C 5220A90002C R
554031 CONDENSER ASSEMBLY,BENT 5403A20168B 5403A20168B R
554160 COMPRESSOR (INVERTER) 5416A90015A 5416A90015A R
554161 COMPRESSOR (CONSTANT) 5416A90021A 5416A90021A R
558511 DRIER ASSEMBLY 5851A20003J 5851A20003J R
559010 FAN ASSEMBLY,PROPELLER 5901A10033A 5901A10033A R
561410 VALVE, EXPANSION (BODY) 6140A90001K 6140A90001K R
561410-1 COIL ASSEMBLY,REVERSING VALVE 6877A20052A 6877A20052A R
561410-2 COIL ASSEMBLY SOLENOID (P/ICE) 6877A20052B 6877A20052B R
561410-3 COIL ASSEMBLY SOLENOID (OIL/S) 6877A20052C 6877A20052C R
561411-1 COIL ASSEMBLY,EXPANSION (A) 6877A20050F - R
561411-2 COIL ASSEMBLY,EXPANSION (B) 6877A20050G - R
561411-3 COIL ASSEMBLY,EXPANSION (C) 6877A20050H - R
561411-4 COIL ASSEMBLY,EXPANSION (D) 6877A20050J - R
566000 SWITCH, PRESSURE (LOW) 3A02524F 3A02524F R
649950 CONTROL BOX ASSEMBLY,OUTDOOR 4995A10101C ABQ31222801 R
658740 REACTOR 5874A90003E 5874A90003E R
668711 PWB(PCB) ASSEMBLY,MAIN(OUTDOOR) 6871A10117D 6871A20697L R
668713 PWB(PCB) ASSEMBLY, SUB (CENTRAL CONTROL) 6871A20484A 6871A20484A Option
W0CZZ-1 CAPACITOR,DRAWING (COMP) 2A00986X 2A00986X R
W0CZZ-2 CAPACITOR,DRAWING (FAN) 2H00660P 2H00660P R
50010 ACCESSORY ASSEMBLY, SINGLE - 5001A30059A R
Location
No.
Description
Part No.
A4UW306FA0 A4UW306FA1
SVC CODE
To Next Page
