Service Manual 267
Exploded View & Replacement Parts List
Parts List (A6UW406FA0 - TPS Inverter)
137213 PANEL ASSEMBLY SIDE 3721A20229A R
263230-1 THERMISTOR ASSEMBLY (ROOM, COND OUT) 6323A20020H R
263230-2 THERMISTOR ASSEMBLY (DISCHARGE SUCTION) 6323A20020J R
263230-3
THERMISTOR ASSEMBLY (DISCHARGE CONSTANT)
6323A20001K R
35211A TUBE ASSEMBLY, SUCTION (INDOOR) 5211A21187A R
352112 TUBE ASSEMBLY, COUPLING 5211A10433A R
430410 BASE ASSEMBLY, WELD 3041A20047K R
435301 GRILLE, DISCHARGE 3530AP1225D R
435511 COVER ASSEMBLY, CONTROL 3A01293X R
435512 COVER ASSEMBLY, TOP 3550AP1213B R
437210 PANEL ASSEMBLY, FRONT SUB 3720AP1212B R
437212 PANEL ASSEMBLY, REAR 3720AP1202C R
447910 BARRIER ASSEMBLY, OUTDOOR 4791A20012E R
546810-1 MOTOR ASSEMBLY, OUTDOOR 4681A20028J R
546810-2 MOTOR ASSEMBLY, OUTDOOR 4681A20028Q R
548490 ACCUMULATOR ASSEMBLY 4849A10003E R
552102 TUBE ASSEMBLY, EXPANSION 5211A22013A R
552112 TUBE ASSEMBLY, CAPILLARY 5211A10430A R
552113 TUBE ASSEMBLY, CONDENSER OUT 5211A23015A R
552115-1 TUBE ASSEMBL, MANIFOLD(OUTDOOR) Ø19.05 5211A22018A R
552115-2 TUBE ASSEMBL, MANIFOLD(OUTDOOR) Ø9.52 5211A22018B R
552116 TUBE ASSEMBLY, REVERSING 5211A21188A R
552203-1 VALVE, SERVICE (Ø19, 05) 2A00499L R
552203-2 VALVE, SERVICE (Ø9, 52) 5220A20001E R
554031-1 CONDENSER ASSEMBLY, BENT 5403A20166J R
554031-2 CONDENSER ASSEMBLY, BENT 5403A20116K R
554160-1 COMPRESSOR SET (INVERTER) 5416A90015A R
554160-2 COMPRESSOR SET (CONSTANT) 5416A90017A R
558511 DRIER ASSEMBLY 5851A20002A R
559010 FAN ASSEMBLY, PROPELLER 5901A10032A R
561411 COIL ASSEMBLY, EXPANSION 6141A30003M R
566000 SWITCH, PRESSURE 3A02524F R
649950 CONTROL BOX ASSEMBLY, OUTDOOR 4995A10118A R
658740 REACTOR 5874A90003A R
668711 PWB(PCB) ASSEMBLY, MAIN(OUTDOOR) 6871A10117E R
668713 PWB(PCB) ASSEMBLY, SUB (CENTRAL CONTROL) 6871A20484A OPTION
669200 RELAY 6920AP3400A R
W0CZZ-1 CAPACITOR, DRAWING (FAN) 2A00986D R
W0CZZ-2 CAPACITOR, DRAWING (COMP) 2A00986A R
349600 BRACKET, MOTOR 4960A10004A R
237200 PANEL CONTROL 3720A10074C R
649950 CASE ASSEMBLY, CONTROL(OUTDOOR) 4995A10118A R
55211G TUBE ASSEMBLY EXPANSION 5211A10434A R
Location No.
Description
Part No.
A6UW406FA0
SVC CODE
