Troubleshooting Guide
4. A4UW306FA1
Th1Th2
Th3
Th4
Check Valve(1 )
Check Valve(2 )
Oil Seperator
Low Pressure S/W
Receiver
Solenoid Valve(1)
Constant
Low Pressure S/W
Compressor
Inverter
Oil
Seperator
Check Valve(1)
Check Valve(2)
Compressor
Accumulator
Heat Exchanger
Reversing
Valve
OUTDOOR UNIT
Field Piping Gas(Ø 15.88) Field Piping Liquid (Ø
6.35)
Refrigerant Flow
Cooling Heating
Drier
Th5
