256 Multi type Air Conditioner
Exploded View & Replacement Parts List
Parts List(Convertible Type-VB chassis)
130911 CABINET ASSEMBLY 3091AP2533A 3091AP2533A R
135303 GRILLE, INLET 5230AP1236A 5230AP1236A R
135310 GRILLE ASSEMBLY, DIFFUSER (INDOOR) 3531A10272E 3531A10272E R
135314 GRILLE ASSEMBLY, INLET SUB 5237AP2817B 5237AP2817B R
137211 PANEL ASSEMBLY, FRONT (INDOOR) 3720AP2767P 3720AP2767P R
146811 MOTOR ASSEMBLY, STEP 4681A20055A 4681A20055A R
152302 FILTER(MECH), A/C 5230AP7093A 5230AP7093A R
159911 VANE ASSEMBLY, HORIZONTAL(UPPER) 5991AP2867B 5991AP2867B R
159912 VANE ASSEMBLY, HORIZONTAL(LOWER) 5991AP7334C 5991AP7334C R
166000 SWITCH, PUSH 6600AP2059B 6600AP2059B R
235450 DISPLAY ASSEMBLY (MECH) 3545AP7224B 3545AP7224B R
237900 WINDOW, DISPLAY 3790AP7080A 3790AP7080A R
249951 CONTROL BOX ASSEMBLY, INDOOR 4995A10107B 4995A10107C R
263230-1 THERMISTOR ASSEMBLY (ROOM, IN) 6323A20004Y 6323A20004Y R
263230-2 THERMISTOR ASSEMBLY (OUT) 6323AQ3226Y 6323AQ3226Y R
267110 REMOTE CONTROLLER ASSEMBLY 6711A20096A 6711A20096A R
268711 PWB(PCB) ASSEMBLY, MAIN 3871A10159B 3871A10159A R
268712 PWB(PCB) ASSEMBLY, DISPLAY 6871AQ3263A 6871AQ3263A R
330870 DRAIN PAN ASSEMBLY 3087AP7233A 3087AP7233A R
342800 BEARING 3H02821B 3H02821B R
346810 MOTOR ASSEMBLY, INDOOR 4681AP2306M 4681AP2306N R
35211A TUBE ASSEMBLY, SUCTION INDOOR 5211AP2813G 5211AP2813H R
352111* TUBE ASSEMBLY, CONNECTOR 5211A20514G 5211A20514G R
352115 TUBE ASSEMBLY, EVAPORATOR - IN 5211AP2810Q 5211AP2810R R
352150 HOSE ASSEMBLY, DRAIN 5251AP2460B 5251AP2460B R
354210 EVAPORATOR ASSEMBLY, FIRST 5421AP2812B 5421AP2812A R
359010 FAN ASSEMBLY, CROSS FLOW 5901AR2351E 5901AR2351E R
W0CZZ CAPACITOR, DRAWING 3H00671A 3H00671A R
Location
No.
Description
Part No.
AMNH
186VBA0
AMNH
246VBA0
SVC
CODE
NOTE) 35211* is for pipe fitting the SVC valve.
To Next Page
