External Dimensions
Figure 38: ARNU123~363NJA4 Dimensions.
NJ Frame
VERTICAL / HORIZONTAL AIR HANDLER
48-11/16
18
21-1/4
48-11/16
49-5/16
2-9/16
1-15/16
21-1/4
12-1/8
1-1/2
9-15/16
2-1/16
18
17
2-1/8
13
4-11/16
1-9/16
1-9/16
1-9/16 1-15/16
1-5/8
14-5/16
Unit: inches
Note: All measurements
have a tolerance of ±1/4 in.
Drain connection
for upflow application
Drain connection
for horizontal
application
Liquid pipe
Vapor pipe
7/8” Wiring
knockouts
7/8” Wiring
knockouts
1-11/16” Wiring
knockouts
Supply Air
opening
Return Air
opening
BOTTOM VIEW
TOP VIEW
SIDE VIEW
FRONT VIEW
17-1/2
20
