- 22 -

LOCA. NO PART NO DESCRIPTION

F801

F812

J57

L04

L05

L102

L210

L402

“(20”)

L501

L502

L503

L506

L551

L801

R443

R545

R546

R547

T401

T402

T802

P301

P802

P902

P903

C531

FR441

FR442

“(20”)

“(21”)

FR443

FR802

FR803

FR901

J30

J33

J39

J149

J154

L01

L10

L631

0FT4001B53C

131-096N

0LA0102K119

0LA1000K119

0LA0102K119

0LA0680K119

0LA0102K119

150-L01W

150-L02C

0LA0102K119

0LA0681K119

150-C02F

0LA0101K119

0LA0681K119

6174Z-6040C

6170VC0003C

6170VMCB01L

366-043K

366-043B

387-603E

366-009D

0RD1103F609

0RF0470J607

0RF0121J607

0RF0101K607

0RF0121K607

0RF0470J607

0RF0470H609

0RF0470K607

0RF0101J607

0RD2200F609

0RD1001F609

0RD1101F609

0RD1500F609

0RD0102F609

0RD2200F609

FUSE,TIME LAG 4000MA 250V

FUSE,FAST BLOE 4000MA 125V

INDUCTOR,10UH K

INDUCTOR,100UH K

INDUCTOR,10UH K

INDUCTOR,0.68UH K

INDUCTOR,10UH K

COIL,H-LINEARITY 57UH

COIL,H-LINEARITY 170UH

INDUCTOR,10UH K

INDUCTOR,6.8UH K

COIL,CHOKE 82UH R1217

INDUCTOR,1.0UH K

INDUCTOR,6.8UH K

FBT,FTMPNG1-6040C

TRANSFORMER,H-DRIVER DRUM 10*12 75UH

TRANSFORMER,SMPS[COIL] EER3940 500UH MONO-ONLY

CONNECTOR,PLUG(4P)

CONNECTOR ASSY,PLUG(2P)

CONNECTOR ASSY,9PIN (IL-J)

CONNECTOR,2.36PAI 1P

110K OHM 1/6 W 5.00% TA52

0.47 OHM 1 W 5.00% TA62

1.2 OHM 1 W 5.00% TA62

1 OHM 2 W 5.00% TA62

1.2 OHM 2 W 5.00% TA62

0.47 OHM 1 W 5.00% TA62

0.47 OHM 1/2 W 5.00% TA52

0.47 OHM 2 W 5.00% TA62

1 OHM 1 W 5.00% TA62

220 OHM 1/6 W 5.00% TA52

1K OHM 1/6 W 5.00% TA52

1.1K OHM 1/6 W 5.00% TA52

150 OHM 1/6 W 5.00% TA52

10 OHM 1/6 W 5.00% TA52

220 OHM 1/6 W 5.00% TA52

LOCA. NO PART NO DESCRIPTION

R01

R03

R04

R05

R06

R07

R09

R10

R11

R12

R15

R16

R17

R19

R21

R22

R23

R25

R26

R27

R29

R41

R51

R52

R101

R102

R103

R107

R108

R109

R110

R111

R112

R113

R114

R116

R118

R201

R205

R206

R207

R208

R212

R213

R214

R215

R216

R217

R218

R219

R220

R221

0RD1002F609

0RD1000F609

0RD3301F609

0RD4701F609

0RD1000F609

0RD1001F609

0RD4701F609

0RD1000F609

0RD2201F609

0RD3902F609

0RD2200F609

0RD1201F609

0RD2201F609

0RD4701F609

0RD1201F609

0RD6200F609

0RD1000F609

0RD1002F609

0RD1202F609

0RD1802F609

0RS0272J607

0RD0392F609

0RD0562F609

0RD1201F609

0RD3601F609

0RD1000F609

0RD6800F609

0RD0272F609

0RD6801F609

0RD2201F609

0RD0912F609

0RD0752F609

0RD1001F609

0RD5101F609

0RD2202F609

0RD2201F609

0RD1001F609

0RD1801F609

0RD4702F609

0RD1201F609

10K OHM 1/6 W 5.00% TA52

100 OHM 1/6 W 5.00% TA52

3.3K OHM 1/6 W 5.00% TA52

4.7K OHM 1/6 W 5.00% TA52

100 OHM 1/6 W 5.00% TA52

1K OHM 1/6 W 5.00% TA52

4.7K OHM 1/6 W 5.00% TA52

100 OHM 1/6 W 5.00% TA52

2.2K OHM 1/6 W 5.00% TA52

39K OHM 1/6 W 5.00% TA52

220 OHM 1/6 W 5.00% TA52

1.2K OHM 1/6 W 5.00% TA52

2.2K OHM 1/6 W 5.00% TA52

4.7K OHM 1/6 W 5.00% TA52

1.2K OHM 1/6 W 5.00% TA52

620 OHM 1/6 W 5.00% TA52

100 OHM 1/6 W 5.00% TA52

10K OHM 1/6 W 5.00% TA52

12K OHM 1/6 W 5.00% TA52

18K OHM 1/6 W 5.00% TA52

27 OHM 1 W 5.00% TA62

39 OHM 1/6 W 5.00% TA52

56 OHM 1/6 W 5.00% TA52

1.2K OHM 1/6 W 5.00% TA52

3.6K OHM 1/6 W 5.00% TA52

100 OHM 1/6 W 5.00% TA52

680 OHM 1/6 W 5.00% TA52

27 OHM 1/6 W 5.00% TA52

6.8K OHM 1/6 W 5.00% TA52

2.2K OHM 1/6 W 5.00% TA52

91 OHM 1/6 W 5.00% TA52

75 OHM 1/6 W 5.00% TA52

1K OHM 1/6 W 5.00% TA52

5.1K OHM 1/6 W 5.00% TA52

22K OHM 1/6 W 5.00% TA52

2.2K OHM 1/6 W 5.00% TA52

1K OHM 1/6 W 5.00% TA52

1.8K OHM 1/6 W 5.00% TA52

47K OHM 1/6 W 5.00% TA52

1.2K OHM 1/6 W 5.00% TA52

The components identified by mark are

critical for safety.

Replace only with part number specified.

For Capacitor & Resistors,

the charactors at 2nd and 3rd

digit in the P/No. means as

follows;

CC, CX, CK, CN : Ceramic

CQ : Polyestor

CE : Electrolytic

RD : Carbon Film

RS : Metal Oxide Film

RN : Metal Film

RF : Fusible

COIL & TRANSFORMER

FUSE

CONNECTOR

RESISTOR
