- 27 -
EXPLODED VIEW PARTS LIST
LOCA. NO PART NO DESCRIPTIONS
104 343-B52A SUPPORTER,PCB
112 2426VSD0019 CPT SET A51QAE320X000TIB
120 6400VA0019D SPEAKER,FULLRANGE H905/020801B 8OHM
150 150-D02X COIL,DEGAUSSING CU 21” 60TURN 12 OHM
153 153-110F DY,DCAN1-21FSAA
170 170-A01D LEAD SET,CPT EARTH
174 6410VEH001B POWER CORD
300 3106V00037F CABINET UNIT
310 5020V00108A BUTTON,CONTROL
320 320-075B SPRING,KNOB
330 5020V00107A BUTTON
520 6871VMMA41R PWB ASSY,MAIN
913 332-057B SCREW ASSY,HEXAGON HEAD
943 1PTF0403116 SCREW,TAP TITE(P) D4.0 L16.0
The components identified by mark is
critical for safety.
Replace only with part number specified.
