LG MODEL : TD-V10050E. TD-V10051E, TD-V10055E, TD-V10050GM, TD-V10056GM
S
AL LOC DESCRIPTION
DLG5988W
MODEL P/NO
DLG5988B DLG3788W
QTY
A500 CABINET ASSEMBLY 3091EL0003B 3091EL0003D 3091EL0003B 1
A510 CAP,DRIER 5006EL3001D 5006EL3001E 5006EL3001D 2
K610 MOTOR ASSEMBLY,WM 4681EL1002A 4681EL1002A 4681EL1002A 1
K600 BRACKET ASSEMBLY 4811EL1002A 4811EL1002A 4811EL1002A 1
K650 PULLEY ASSEMBLY,MOTOR 4561EL3002A 4561EL3002A 4561EL3002A 1
K640 SWITCH,MICRO 3W40025D 3W40025D 3W40025D 1
K620 CLAMP 4860EL3001A 4860EL3001A 4860EL3001A 2
K510 BLOWER ASSEMBLY 5835EL1002A 5835EL1002A 5835EL1002A 1
K520
HOUSING ASSEMBLY (MECH),BLOWER
3661EL1001C 3661EL1001C 3661EL1001C 1
K550 THERMISTOR ASSEMBLY 6323EL2001B 6323EL2001B 6323EL2001B 1
K560 THERMOSTAT ASSEMBLY 6931EL3002A 6931EL3002A 6931EL3002A 1
K530 DUCT ASSEMBLY 5209EL1006A 5209EL1006A 5209EL1006A 1
K400 TUB,DRUM[BACK] 3044EL0002B 3044EL0002B 3044EL0002B 1
F200 DUCT ASSEMBLY 5209EL1001D 5209EL1001D 5209EL1001D 1
K250 ROLLER ASSEMBLY 4581EL3001A 4581EL3001A 4581EL3001A 1
M210 FUNNEL 3016EL1001A 3016EL1001A 3016EL1001A 1
M230 THERMOSTAT ASSEMBLY 6931EL3003C 6931EL3003C 6931EL3003C 1
M220 THERMOSTAT ASSEMBLY 6931EL3004B 6931EL3004B 6931EL3004B 1
M240 SENSOR ASSEMBLY 6501EL3001A 6501EL3001A 6501EL3001A 1
M140 GUIDE,BURNER 4974EL1001A 4974EL1001A 4974EL1001A 1
M150 PIPE ASSEMBLY 5201EL3001A 5201EL3001A 5201EL3001A 1
M110 VALVE ASSEMBLY,GAS 5221EL2002A 5221EL2002A 5221EL2002A 1
M190 PIPE ASSEMBLY 5201EL2001A 5201EL2001A 5201EL2001A 1
M181 SEAL 4036EL3002A 4036EL3002A 4036EL3002A 1
M170 ORIFICE (Natural gas) 4948EL4001B 4948EL4001B 4948EL4001B 1
M171 ORIFICE (Propane gas) 4948EL4002B 4948EL4002B 4948EL4002B 1
M180 CONNECTOR (MECH),PIPE 4932EL4001A 4932EL4001A 4932EL4001A 1
M160 IGNITER 5318EL3001A 5318EL3001A 5318EL3001A 1
A600 HARNESS,PWB 6877EL1008A 6877EL1008A 6877EL1008A 1
K100 TUB ASSEMBLY,DRUM 3045EL1002E 3045EL1002E 3045EL1002E 1
K140 SEAL 4036EL3001A 4036EL3001A 4036EL3001A 2
K120 LIFTER 4432EL1002B 4432EL1002B 4432EL1002B 3
K130 BELT,POLY-V 4400EL2001A 4400EL2001A 4400EL2001A 1
K210 TUB,DRUM[FRONT] 3044EL1001B 3044EL1001B 3044EL1001B 1
K221 LAMP ASSEMBLY 6913EL3002C 6913EL3002C 6913EL3002C 1
K222 LAMP ASSEMBLY 6913EL3001A 6913EL3001A 6913EL3001A 1
K250 ROLLER ASSEMBLY 4581EL3001A 4581EL3001A 4581EL3001A 1
K240 DUCT ASSEMBLY 5209EL1002A 5209EL1002A 5209EL1002A 1
K320 COVER,GUIDE 3550EL1006B 3550EL1006B 3550EL1006B 1
K340 SENSOR 6500EL3001A 6500EL3001A 6500EL3001A 2
K330 GUIDE,FILTER 4974EL1003B 4974EL1003B 4974EL1003B 1
K310 FILTER ASSEMBLY,LINT 5231EL1003B 5231EL1003B 5231EL1003B 1
A390 FRAME ASSEMBLY 3211EL1003A 3211EL1003A 3211EL1003A 1
A310 COVER,CABINET 3550EL0005A 3550EL0005B 3550EL0005A 1
A330 SWITCH ASSEMBLY,SAFETY 6601EL3001A 6601EL3001A 6601EL3001A 1
A320 LATCH ASSEMBLY 4027EL1001A 4027EL1001A 4027EL1001A 1
A400 DOOR ASSEMBLY 3581EL0002A 3581EL0002A 3581EL0002D 1
A420 DOOR FRAME,OUTER 3212EL1009A 3212EL1009A 3212EL1010C 1
A410 LATCH,HOOK 4026EL3007A 4026EL3007A 4026EL3007A 1
A460 GASKET 4986EL2004A 4986EL2004A 4986EL2004A 1
A210 TOP PLATE ASSEMBLY 3457ER1006D 3457ER1006J 3457ER1006E 1
A110 PANEL,CONTROL 3720EL0001B 3720EL0001H 3720EL0001D 1
A140 KNOB,ROTARY 4940ER3016A 4940ER3016A 4940ER3016A 1
A130 PWB(PCB) ASSEMBLY,MAIN 6871EC1121B 6871EC1121B 6871EC1121F 1
A120 PWB(PCB) ASSEMBLY,DISPLAY 6871EC1115B 6871EC1115B 6871EC1115D 1
CAUTION : Before replacing any part of these components,
read carefully the safety precautions in this manual.
A550 POWER CORD ASSEMBLY 6411ER1005B 6411ER1005B 6411ER1005B 1
A700 RACK 3750EL1001B 3750EL1001B 3750EL1001B 1
