LG DLE7000W User Manual

9PRODUCT OVERVIEW
ENGLISH
d Water inlet hose connection (for steam models)
e Exhaust duct oulet
Product Specifications
Accessories
Optional Accessories (sold separately)
a Drying rack (No. 3750EL001C)
b Side vent kit (Kit No. 383EEL9001B)
NOTE
• For your safety and extended product life, use only authorized components. The manufacturer is not
responsible for product malfunction or accidents caused by the use of unauthorized components or
parts.
Model DL*700** / DL*710** / DL*715**
Electrical Requirements
Please refer to the rating label for detailed
information.
Dimensions (Width X Depth X Height) 27'' X 29 1/2'' X 44 1/2'' (68.6 cm X 75.0 cm X 113.0 cm)
Maximum Depth with Door Open 50 1/4'' (127.5 cm)
Net Weight
Gas : 114.0 lb (51.7 kg)
Electric : 111.3 lb (50.5 kg)
Capacity 7.3 cu.ft. (22.5 lb / 10.2 kg)
Gas Requirements
NG: 4 - 10.5-inch (10.2 - 26.7 cm) WC
LP: 8 - 13-inch (20.4 - 33.1 cm) WC
C
E
R
T
I
F
I
E
D
D
E
S
I
G
N

LG DLE7000W Specifications

General

Type	rear control top load dryer; front load; electric
Color	white (w)
Dryer Capactity	7.3 cu. ft.
Number of Cycles	8
Number of Options	7; wrinkle care, control lock, more time, less time, damp dry signal, energy saver, signal
Drying Levels	3
Venting	vented
Temperature Settings	3
Control Panel	digital and knobs
Cycle Signal	yes
Interior Light	no
Drying Rack	no
Sensor Dry Option	normal, perm press, heavy duty, bedding, delicates, speed dry (manual dry), air dry (manual dry), freshen up (manual dry); yes
Sanitize Option	no
Steam	no
Smart Home	yes; lg thinq app
Remote Control	no
Wi-Fi	no
Electrical Requirements	240v, 30 amps
Voltage	240 volts
Current	30

Weight and Dimensions

Depth	29 1/2" (50 1/4" d with door open)
Height	44 1/4 inch
Width	27 inch
Net Weight	114.9 lbs
