17
ENGLISH
Reversing the door (cont.)
1. Move door to left side and insert a hinge to hinge hole.
2. Hold on hinge while screw down a hinge
(to prevent door dropping).
3. Insert latch to right side and install screws.
4. Screw down four dummy screws right side.
5. Check that the door closes and latches properly.
Latch
Screw
Hinge Screw
Hinge
Dummy
Screw
Swing Door
Hinge hole
INSTALLATION INSTRUCTIONS
w
WARNING







THE DRYER DOOR IS VERY LARGE AND HEAVY. Failure to follow
the instructions below can result in damage to the dryer,
property damage or injury to persons.
