LG DLG0452W Service Manual

28
1.
Open the top plate.
2.
Remove Cover Cabinet.
3.
Disconnect the door lamp and electro
sensor connector.
4.
Remove 4 screws.
5.
Disassemble the Tub Drum [Front].
1.
Open the top plate.
2.
Remove the Cover Cabinet and
Tub drum [front].
3.
Disengage belt from motor and idler pulleys.
4.
Carefully remove Drum out through front of dryer.
-1
-2
-1
1.
Open the door.
2.
Remove the screw holding the drum lamp shield
in place.
3.
Slide the shield up and remove.
4.
Remove the bulb and replace with a 15 watt,
120 volt candelabra-base bulb.
5.
Replace the lamp shield and screw.

LG DLG0452W Specifications

General

Brand	LG
Model	DLG0452W
Category	Dryer
Language	English
