Button Description
WPS • To connect WPS to AP(Access Point)
RESET
• Reboot
• Reset to Factory Default
LED Description
POWER
• Solid White : Power on
• Off : Power is not supplied to the PoE WLAN Bridge
WLAN
• Solid White : WLAN Activity are in process
• Blinking White : Wireless data is being sent or received.
• Solid Red : WLAN is accessing or access is fail
• Blinking Red : The Wireless signal is weak signal
• Off : WLAN is not used
CAMERA
• Solid White : CAMERA link is detected
Data Transmission on the port
• Off : No data transmission
1. Appearance Description for PoE WLAN Bridge
Fig 1. Front/Right side View
1. Front/Right side Panel
- The Right side panel has the 2-Button and Front panel has
status LEDs in the following figure.
Table 1. Button/Led Description
1 / 5
POWER
CAMERA
WLAN
WPS
RESET
