Chapter 6. BUFFER MEMORY CONFIGURATION AND FUNCTIONS
6 - 2
Address
(Decimal)
Function Description
Default
Setting
Read /
Write
32 Temperature conversion value of the channel 5
33 Digital conversion value of the channel 5
34 Error code of the channel 5
35 Temperature conversion value of the channel 6
36 Digital conversion value of the channel 6
37 Error code of the channel 6
38 Temperature conversion value of the channel 7
39 Digital conversion value of the channel 7
40 Error code of the channel 7
41 Temperature conversion value of the channel 8
42 Digital conversion value of the channel 8
43 Error code of the channel 8
44 Temperature conversion value of the channel 9
45 Digital conversion value of the channel 9
46 Error code of the channel 9
47 Temperature conversion value of the channel 10
48 Digital conversion value of the channel 10
49 Error code of the channel 10
50 Temperature conversion value of the channel 11
51 Digital conversion value of the channel 11
52 Error code of the channel 11
53 Temperature conversion value of the channel 12
54 Digital conversion value of the channel 12
55 Error code of the channel 12
56 Temperature conversion value of the channel 13
57 Digital conversion value of the channel 13
58 Error code of the channel 13
59 Temperature conversion value of the channel 14
60 Digital conversion value of the channel 14
61 Error code of the channel 14
62 Temperature conversion value of the channel 15
63 Digital conversion value of the channel 15
64 Error code of the channel 15
•
Temperature conversion value
: 10 times of a real temperature is displayed.
•
Digital conversion value
▶
If a temperature conversion value is converted
into a value within 0 to 16000, that value is a
digital conversion value.
▶
It can be used as a process value of the PID
control module.
▶
Expression
Digital conversion value = (16000/
measuring temperature range)
×
(temperature conversion value –
minimum measuring temperature)
•
Error code
16 : Disconnection detection error
17 : Upper or lower overflow
18 : Reference junction compensation device
error
Read
Only
65 SET data
Bit On(1) : New setting values are set for the
contents of address 0 to 16.
Bit Off(0) : The existing values of address 0 to 16
remains.
No
setting
R/W
66 Run channel information Bit On(1) : Running, Bit Off(0) : Stop
Read
only
67 Setting Error information
Bit On(1) : if other value than 0 to 6 is set for
specifying the type of thermocouples in
the address 1 to 16.
Bit Off(0) : If 0 to 6 is set for specifying the type of
thermocouples in the address 1 to 16.
Read
only
To Next Page
