39
MAINTENANCE
ENGLISH
• Lower or remove the top left shelf to allow
the water filter to rotate all the way down.
Pinch the sides to open the water filter cover.
• Replacing the water filter causes a small amount
of water (around 25 cc) to drain.
• Wrap a cloth around the front end of the water
filter cover to collect any leaking water. Hold the
water filter upright, once it is removed, to
prevent any remaining water from spilling out of
the water filter.
3
Pull the water filter downward and turn it
counterclockwise before pulling it out. Make
sure to rotate the filter down completely
before pulling it out of the manifold hole.
4
Replace with a new water filter.
• Take the new water filter out of its packing
and remove the protective cover from the o-
rings. With the water filter tabs in the
horizontal position, push the new water filter
into the manifold hole and turn it clockwise
until it stops.
5
Close the water filter cover. The cover will click
when closed correctly.
6
After the water filter is replaced, dispense
about 10 liters of water (flush for
approximately 5 minutes) to remove trapped
air and contaminants from the system.
• Do not dispense the entire 10 liters amount
continuously. Press and release the dispenser
pad for cycles of 30 seconds ON and 60 seconds
OFF.
7
After changing the filter, press and hold the
Water Filter
button for three seconds to reset
the indicator light.
• Failure to replace filters when required or using
non LG authorised water filters can cause the
filter cartridge to leak and result in property
damage.
