Parts List
• 42K/48K/60K
137213 PANEL ASSY, SIDE 3720AP1215B 3720AP1215B 3720AP1215B 3720AP1215B 3720AP1215B R
263230 THERMISTOR ASSY 3Q35015E 3Q35015E - 3Q35015E - R
268711 PWB(PCB) ASSY, DEICER 6871A20015U 6871A20015N - 6871A20015N - R
435301 GRILLE, DISCHARGE 3530AP1225B 3530AP1225B 3530AP1225B 3530AP1225B 3530AP1225B R
435512 COVER ASSY, TOP(OUTDOOR) 3550AP1213B 3550AP1213B 3550AP1213A 3550AP1213B 3550AP1213B R
437210 PANEL ASSY, FRONT SUB 3720AP1212B 3720AP1212B 3720AP1212B 3720AP1212B 3720AP1212B R
437212 RNAEL ASSY, REAR 3720AP1202C 3720AP1202C 3720AP1202C 3720AP1202C 3720AP1202C R
546810 MOTOR ASSY, OUTDOOR 4680AP2135M 4681A20008R 4681A20008P 4681A20008P 4681A20008P R
552111 TUBE ASSY, CAPILLARY 5425AP7109L 5211A10120A 5211A10119A 5211A10120B 5211A10120C R
552115
TUBE ASSY, MANIFOLD(OUTDOOR) 5211AP3988A 5211AP3988A 5211A30124B 5211AP3988A 5211AP3988A R
552201 VALVE, CHECK 4A00322A 4A00322A - 4A00322A - R
552202 VALVE, REVERSING 3A02080A 3A02080A - 3A02080A - R
552203-1 VALVE, SERVICE 2A00393Q 2A00393Q 2A00393Q 2H0189G 2H0189G R
552203-2 VALVE, SERVICE 2A00499A 2A00499A 2A00499A 2A00499A 2A00499A R
554031-1 CONDENSER ASSY, BENT 5403AP2378K 5403AP2378D 5403A20001H 5403AP2378D 5403A20003M R
554031-2 CONDENSER ASSY, BENT 5403AP2378Z 5403AP2378F 5403A20001H 5403AP2378F 5403A20003P R
554160 COMPRESSOR ASSY, FINAL 5416A10001A 5417A30002A 5417A30002A 5417A20008G 5417A20008G R
559010 FAN ASSY, PROPELLER 1A00195B 1A00195B 1A00195B 1A00195B 1A00195B R
561410 COIL ASSY, REVERSING VALVE 3A02028B 3A02028B - 3A02028B - R
566000 SWITCH, PRESSURE 3A01100A 3A01100A - 3A01100A - R
567480 P.T.C ASSY 3A01911B - - - - R
649950
CONTROL BOX ASSY, OUTDOOR 6625AP2772R 6615AP2772Y 6615AP2772Z 6615AP2772Y 6615AP2772Z R
566001 SWITCH, MAGNET 2A01031C 2A01031A 2A01031C 2A01031A 2A01031C R
W6920 RELAY 3A00261C 3A00261C - 3A00261C - R
W0CZZ-1 CAPACITOR, DRAWING 2A00986D 2A00986D 2A00986D 2A00986D 2A00986D R
W0CZZ-2 CAPACITOR, DRAWING 6120AR2194Y - - - - R
LB-F4261HL LB-E4881HL LB-E4881CL LB-E6081HL LB-E6081CL
LB-F4263HL LB-E4883HL LB-E4883CL LB-E6083HL LB-E6083CL
LOCATION No. DESCRIPTION
Part No.
REMARKS
