LG LFX25971 Series - Safety Information; Basic Safety Precautions

Step 3-1: Main PCB Step 2-2-4 : Door Gasket - Detail (Excluding LFX23961xx)
Door Gasket Sealing
 Door Liner, Upper Flange
 Door Liner, Upper Flange
 Door Liner, Gasket Slot
 Holder, Gasket Side
Align with the top of
the door liner.
1. Remove the cover,
PCB (3 or 4 screws).
3. Install the new Main PCB
and reconnect all electrical
wires.
2. Disconnect all wiring
connectors from the Main
PCB.
4
Step 3-2 : Harness Adapter (2008 models)
4. Connect the new harness adapter as shown. 5. Replace the Cover, PCB. 6. Attach the yellow sticker on the
PCB Cover.
